Specifications
for pool/spa,for keeping water in constant temperature
Titanium heat exchanger
28-45C outlet water
CE
we are a golden supplier which has got certificate from TUV and .
1. Over 8 years of Heat pump production.
2. Passed ISO9001:2012 and TUV, CE, EN14511 Certificate.
3. Got 3 National standard laboratories passed TUV certificate.
4. Has a branch office in Frankfurt Germany.
5. Provide Professional and flexible OEM service.
Swimming pool heat pump
Model: DE-36W/CY
Deron swimming pool heat pump applies the heat pump technology which move heat from the surroundings into the pool/spa water to keep a comfortable temperature for people. The adoption of pure titanium heat exchanger, not only because of its superb resistance to corrosive water, but also its higher heat exchanger rate. It's widely used in house, villa, and hotel swimming pool.These units have got CE approval.
1) The 100% titanium heat exchanger use seamless pure titanium tube as heat conductor, can ensure the titanium heat exchanger used for a long time without any cost in the after-sale services.
2) The well-known brand throttling device-Emersonexpansion valve are included, it can control the refrigerant flow accurately.
3) Adjustable defrosting according to different weather conditions (with four way valve inside).
4)Water flow switch is optional .
5) Special design for the fan shroud, with accurate and equal distance between the fan blades and the fan shroud, low vibration, and low noise when running.
6)Compact design and accurate workmanship for fixing the case with bolts and nuts, no damage to the case coating, avoiding corrosion and rust to the case.
7) Multiple protections to protect the compressor and the heat exchanger, like anti-freezing protection, water flow protection, over high pressure protection, over low pressure protection insufficient water flow protection etc.
8) General testing and operational test carried out for every unit to ensure the superior quality and feature before well package in factory.
9) Modular and diversifying design: We can add on more units or design heat pumps according to customers’ requirement.
| Model | DE-13W/CY | DE-18W/CY | DE-27W/CY | DE-36W/CY | |
| Power supply | (V/ph/Hz) | 220/1/50 | 220/1/50 | 220/1/50 | 380/3/50 |
| *Heating capacity | (kw) | 4.8 | 7.1 | 10.5 | 14.5 |
| (BTU) | 16377 | 24224 | 35825 | 49472 | |
| *Power input | (kw) | 1 | 1.4 | 2.1 | 2.9 |
| *Test condition | *Ambient temp.(Dry Bulb/Wet Bulb): 20°C /15°C, Water temp.(in /out): 15°C/28°C | ||||
| **Cooling capacity | (kw) | 3.7 | 5.3 | 7.5 | 10.5 |
| (BTU) | 12624 | 18083 | 25589 | 35825 | |
| **Power input | (kw) | 1.4 | 1.9 | 2.8 | 3.9 |
| **Test condition | **Ambient temp.(Dry Bulb/Wet Bulb): 35°C /24°C, Water temp.in: 28°C | ||||
| Refrigerant | R410A | ||||
| Compressor | (type) | Rotary | Scroll | ||
| (number) | 1 | 1 | 1 | 1 | |
| Fan | (type) | Axial flow type with Nylon fan blade | |||
| (discharging) | Horizontal | ||||
| (number) | 1 | 1 | 1 | 1 | |
| (air flow)(m3/h) | 1000 | 1200 | 2800 | 5000 | |
| Evaporator | Aluminium/Cu lamellar tube evaporator | ||||
| Condenser (heat exchanger) | Titanium-in-PVC heat exchanger | ||||
| Throttling device | Emerson thermal expansion valve | ||||
| Controller | Indoor Digital Controller | ||||
| Required hot water flow rate | (m3/h) | 2 | 3 | 4.5 | 6 |
| Water connection diameter | (mm) | 50 | 50 | 50 | 50 |
| Noise | dB(A) | ≤48 | ≤48 | ≤48 | ≤50 |
| Max. current | (A) | 9.5 | 13 | 7.2 | 10 |
| Level again electric shock | I | I | I | I | |
| Water proof | IPX4 | IPX4 | IPX4 | IPX4 | |
| Rated outlet water temp. | (°C) | 28 | 28 | 28 | 28 |
| Max. water temp. | (°C) | 45 | 45 | 45 | 45 |
| Operation temp. range | (°C) | -10-45 | -10-45 | -10-45 | -10-45 |
| Net weight | (kg) | 58 | 67 | 84 | 95 |
| Net size | (mm) | 1005X350X610 | 1005X350X610 | 1115X485X715 | 755X595X1470 |
While you are considering
We provide free consolation on the model of heat pump system, system design, and cost estimation that can be suit for your needs.
l After you purchase the product
The first installation can be carried out by us, by sending engineers to your country helping you with the installation, in a safe and efficiency manner.
l Satisfaction guarantee:
There is an 18 months warrantee for air-water heat pumps and water-water heat pumps, and 24 months warrantee for swimming pool heat pumps.
Our products have been widely sold to more than 30 countries and enjoyed a good sales in the markets
♥ If you want to know more about our products welcome to contact us in any time, And welcome to Deron company!
