Specifications
1)Special for Swimming Pool2)Automatic Defrosting
3)High COP up to 5.0
4)Titanium Heat Exchanger
5)Small & nice look.
Deron Swimming Pool Heat Pump
---special for swimming pool heating/cooling
Model: DE-52W/DY
Deron swimming pool heat pump applies the heat pump technology which move heat from the surroundings into the pool/spa water to keep a comfortable temperature for people. The adoption of pure titanium heat exchanger, not only because of its superb resistance to corrosive water, but also its higher heat exchanger rate. It's widely used in house, villa, and hotel swimming pool.These units have got CE approval.
1) The 100% titanium heat exchanger use seamless pure titanium tube as heat conductor, can ensure the titanium heat exchanger used for a long time without any cost in the after-sale services.
2) The well-known brand throttling device-Emersonexpansion valve are included, it can control the refrigerant flow accurately.
3) Adjustable defrosting according to different weather conditions (with four way valve inside).
4)Water flow switch is optional .
5) Special design for the fan shroud, with accurate and equal distance between the fan blades and the fan shroud, low vibration, and low noise when running.
6)Compact design and accurate workmanship for fixing the case with bolts and nuts, no damage to the case coating, avoiding corrosion and rust to the case.
7) Multiple protections to protect the compressor and the heat exchanger, like anti-freezing protection, water flow protection, over high pressure protection, over low pressure protection insufficient water flow protection etc.
8) General testing and operational test carried out for every unit to ensure the superior quality and feature before well package in factory.
9) Modular and diversifying design: We can add on more units or design heat pumps according to customers’ requirement.
| Model | DE-52W/DY |
| Power supply(V/ph/Hz) | 380/3/50 |
| Compressor rated power(kw) | 5.2 |
| Heating capacity(kw) | 22 |
| Power input(kw) | 3.7 |
| Refrigerant | R417A |
| Refrigerant weigh(g) | 2500 |
| Max.current(A) | 15 |
| Rated water temp.(°C) | 28 |
| Level against electric shock | I |
| Water-proof grade | IPX4 |
| Net weight(kg) | 140 |
| Net size(mm)-(L*W*H) | 800*780*1000 |
| Required water flow rate(m3/h) | 9 |
| Water connection(mm) | 50mm |
| Operation temp.range(°C) | -10-45 |
| Noise dB(A) | ≤64 |
Test condition: Ambient temp.(DB/WB):20°C/15°C
Water temp.(Initial/Final):15°C/28°C
.
8 Years of Manufacture Experience!
Three World-class Laboratories approved by TUV.
Fast Delivery!
♥ Welcome to contact us in any time for further information! Your questions are highly appreciated and welcome to our company!
