Heavy Duty Shield Anchors With Loose Bolrs
US$ 0.1 - 1
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
FIXINGMORE
Model Number:
OEM
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Heavy Duty Wedge Type Expansion AnchorUS$ 0.1 - 1MOQ: 1000 Pieces -
China Supplier High Quality Heavy Duty Concrete AnchorsUS$ 0.1 - 1MOQ: 1000 Pieces
-
China Made YZP Bright Concrete Drop In Anchor Carbon SteelUS$ 0.1 - 1MOQ: 1000 Pieces
-
Hilti Drop in Anchor M16US$ 0.1 - 1MOQ: 1000 Pieces
-
High Quality Drop in Anchor M12US$ 0.1 - 1MOQ: 1000 Pieces
Place of Origin
Zhejiang, China
Brand Name
FIXINGMORE
Model Number
OEM
Standard
Other, DIN, ANSI,ASTM, JIS, GB,etc
Heavy Duty Anchor With Hex Nut
Base Material
Cracked Concrete
Uncracked Concrete
Sand-limestone Solid
Product Advantages
1. ISO9001:2000 Certified ,CE, GS
2. Quality Control inspection Before Shipment
3. Appearance: Bright neat body, without any burrs
4. Tolerances: Precision Tolerances to Customer Specification
5. Non-standard/ OEM/ODM/customized service provided
Specifications Model
A. METRIC
| CODE | SIZE | DRILL DIA. | LENGTH | MINIMUM EMB. | TENSIONS(KN.)** |
| HDA06060 | M6 | 10mm | 60mm | 50mm | 5.8 |
| HDA06070 | M6 | 70mm | |||
| HDA06090 | M6 | 90mm | |||
| HDA06110 | M6 | 110mm | |||
| HDA08070 | M8 | 12mm | 70mm | 60mm | 7.6 |
| HDA08080 | M8 | 80mm | |||
| HDA08100 | M8 | 100mm | |||
| HDA08120 | M8 | 120mm | |||
| HDA10085 | M10 | 15mm | 85mm | 71mm | 11.9 |
| HDA10100 | M10 | 100mm | |||
| HDA10110 | M10 | 110mm | |||
| HDA10130 | M10 | 130mm | |||
| HDA10180 | M10 | 180mm | |||
| HDA12100 | M12 | 18mm | 100mm | 80mm | 14.3 |
| HDA12110 | M12 | 110mm | |||
| HDA12120 | M12 | 120mm | |||
| HDA12140 | M12 | 140mm | |||
| HDA12170 | M12 | 170mm | |||
| HDA16120 | M16 | 24mm | 120mm | 100mm | 19.1 |
| HDA16140 | M16 | 140mm | |||
| HDA16170 | M16 | 170mm | |||
| HDA20170 | M20 | 28mm | 170mm | 125mm | 23.8 |
| HDA20190 | M20 | 190mm | |||
| HDA20220 | M20 | 220mm | |||
| HDA20260 | M20 | 260mm |
B. I NCH
| CODE | SIZE | DRILL DIA. | ANCHOR LEN. | MINIMUN EMB. | MAX. FIXTURE THICK. | TENSION(LBS.)** |
| HDA14134 | 1/4" x 1-3/4" | 1/4" | 1-3/4" | 1-1/4" | 1/2" | 325 |
| HDA143 | 1/4" x 3" | 1/4" | 3" | 1-3/4" | 1-3/4" | 485 |
| HDA38214 | 3/8" x 2-1/4" | 3/8" | 2-1/4" | 2" | 1/4" | 865 |
| HDA383 | 3/8" x 3" | 3/8" | 3" | 2-3/4" | 1" | 1105 |
| HDA38312 | 3/8" x 3-1/2" | 3/8" | 3-1/2" | 2-3/4" | 1-1/2" | 1105 |
| HDA384 | 3/8" x 4" | 3/8" | 4" | 2-3/4" | 2" | 1105 |
| HDA12234 | 1/2" x 2-3/4" | 1/2" | 2-3/4" | 2-1/2" | 1/4" | 1225 |
| HDA12312 | 1/2" x 3-1/2" | 1/2" | 3-1/2" | 3" | 1/4" | 1640 |
| HDA12434 | 1/2" x 4-3/4" | 1/2" | 4-3/4" | 3-1/4" | 1-1/2" | 2160 |
| HDA12534 | 1/2" x 5-3/4" | 1/2" | 5-3/4" | 3-1/4" | 2-1/2" | 2160 |
| HDA583 | 5/8" x 3" | 5/8" | 3" | 2-3/4" | 1/4" | 1500 |
| HDA584 | 5/8" x 4" | 5/8" | 4" | 3-1/2" | 1/4" | 2210 |
| HDA585 | 5/8" x 5" | 5/8" | 5" | 3-3/4" | 1-1/4" | 2755 |
| HDA586 | 5/8" x 6" | 5/8" | 6" | 3-3/4" | 2-1/4" | 2755 |
| HDA58812 | 5/8" x 8-1/2" | 5/8" | 8-1/2" | 3-3/4" | 4-3/4" | 2755 |
** Tabulated load values are for anchors installed in concrete(Concrete C20/25).
Concrete compressive strength must be at the specified minimum at the time of installation.
