Help CenterHilti Drop in Anchor M16
US$ 0.1 - 1
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Fixingmore
Model Number:
OEM
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Quality Drop in Anchor M12US$ 0.1 - 1MOQ: 1000 Pieces -
Drop-in Anchor With LipUS$ 0.1 - 1MOQ: 1000 Pieces
-
Lipped Drop in Anchor With Zinc PlatedUS$ 0.1 - 1MOQ: 1000 Pieces
-
Carbon Steel Blue White Zinc Plated Drop In Anchor M10 M12US$ 0.1 - 1MOQ: 1000 Pieces
-
Cut Expansion Anchor for Grille 5/8"US$ 0.1 - 1MOQ: 1000 Pieces
Place of Origin
Zhejiang, China
Brand Name
Fixingmore
Model Number
OEM
Standard
Other, DIN, ANSI,ASTM, JIS, GB,etc
Drop in Anchor
Base Material
1.Base material of concrete,hardnatureal stone.
2.For fastening mediunloads,for example suspended ceiling pipes rails,channels,panels,brackets etc.
(Solid concrete, solid block, hard stone, Piping, ventilation systems, cable ducts)
Product Advantages
1. ISO9001:2000 Certified ,CE, GS
2. Quality Control inspection Before Shipment
3. Appearance: Bright neat body, without any burrs
4. Tolerances: Precision Tolerances to Customer Specification
5. Non-standard/ OEM/ODM/customized service provided
Specifications Model
A. METRIC
| CODE | SIZE | DRILL DIA. | DRILL DEP. | THREAD LEN. | TENSION(KN.)** |
| DA0630 | M6x30 | 8 | 33 | 13.5 | 1.5 |
| DA0830 | M8x30 | 10 | 33 | 13.5 | 2 |
| DA1030 | M10x30 | 12 | 33 | 13.5 | 3 |
| DA1040 | M10x40 | 12 | 44 | 18 | 3 |
| DA1250 | M12x50 | 15 | 54 | 22.5 | 5.3 |
| DA1251 | M12x50 | 16 | 54 | 22.5 | 5.3 |
| DA1665 | M16x65 | 20 | 71 | 29 | 7.4 |
| DA2080 | M20x80 | 25 | 86 | 36 | 11 |
B. I NCH
| CODE | SIZE | DRILL DIA. | DRILL DEP. | THREAD LEN. | TENSION(LBS.)** |
| DA14 | 1/4" | 3/8" | 1" | 7/16" | 391 |
| DA516 | 5/16" | 3/8" | 1" | 7/16" | 420 |
| DA38 | 3/8" | 1/2" | 1-9/16" | 5/8" | 712 |
| DA12 | 1/2" | 5/8" | 2" | 1-3/16" | 1047 |
| DA58 | 5/8" | 7/8" | 2-1/2" | 1-3/16" | 1833 |
| DA34 | 3/4" | 1" | 3-3/16" | 1-3/8" | 2391 |
** Tabulated load values are for anchors installed in concrete(Concrete C20/25).
Concrete compressive strength must be at the specified minimum at the time of installation.
