Full Icon Display Clamp Multi Meter,Ac Digital Clamp Meters with Continuity Buzzer
USD $29.01 - $33
/ Set
1 Set(Min.Order)
- 5000 Set / Sets per Month
- shenzhen
- T/T L/C D/P D/A Credit Card
You May Like
Product Details
| Place of Origin: | Guangdong, China | Model Number: | UT206 | Display Type: | Digital Only |
| Measuring Current Range: | AC:400A/1000A | Measuring Voltage Range: | AC:4V/40V/400V/600V,DC400mV/4V/40V/400V/600V | Measuring Resistance Range: | 400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ |
| Measuring Capacitance Range: | 40nF/400nF/4μF/40μF/200μF | Operating Temperature: | -40 °C ~ 1000°C , ±(2%+8) | Dimensions: | 236mm X 97mm X40 mm |
| Weight: | 0.95kg |
Product Description
Specifications
Full Icon Display Clamp Multi Meter,Ac Digital Clamp Meters with Continuity Buzzer
| Specifications | Range | Best Accuracy |
| Model | UT206A | |
| AC Current (A) | 400A/1000A | ±(1.5%+5) |
| AC Voltage (V) | 4V/40V/400V/600V | ±(1.2%+5) |
| DC Voltage (V) | 400mV/4V/40V/400V/600V | ±(0.8%+1) |
| Resistance (Ω) | 400Ω/4KΩ/40KΩ/400KΩ/4MΩ/40MΩ | ±(1%+2) |
| Frequency (Hz) | 10Hz~10MHz | ±(0.1%+3) |
| Temperature (°C) | -40 °C ~ 1000°C | ±(2%+8) |
Features
| Display Count | 4000 | |
| Auto Range | √ | |
| Jaw Capacity | 40mm | |
| Diode | √ | |
| Auto Power Off | √ | |
| Continuity Buzzer | √ | |
| Low Battery Indication | √ | |
| Data Hold | √ | |
| Relative Mode | √ | |
| LCD Backlight | √ | |
| Full Icon Display | √ | |
| Input Impedance for DCV | Around 10MΩ | √ |
Side View : streamline design
Jaw and Torch light :
Packaging & Shipping
| Power | 9V Battery(6F22) | |
| LCD Size | 37mm X 18 mm | |
| Product Color | Red and Grey | |
| Product Net Weight | 350g | |
| Product Size | 236mm X 97mm X40 mm | |
| Standard Accessories | Battery, Test Lead,Carrying Bag,Point Contact Temperature Probe | |
| Standard Individual Packing | Gift Box, English Manual | |
| Standard Quantity Per Carton | 20 PCs | |
| Standard Carton Measurement | 530mm X 360mm X 385mm (0.073 CBM Per Standard Carton) | |
| Standard Carton Gross Weight | 17Kg | |
