Specifications
industrial food rotary dryer:1) 30 years' rotary kiln dryer making experience.
2) factory sale rotary kiln dryer.
Excellent quality factpry sale rotary drum kiln industrial food rotary dryer
Industrial food rotary dryer
Work site of industrial food rotary dryer
Introduction of industrial food rotary dryer
1.New type industrial food rotary dryer for fertilizer with new type heat pipe structure, give
material an indirect heated dryer.
2. Under the traction of hot air blower,enter and heating heat pipe,heat pipe heat transfer
to the material,due to material and heat pipe to full contact,so the drying out of material to
is better than common industrial food rotary dryer's drying effect of the market.
3. The new type industrial food rotary dryer's device enables real-time water vapor emitted
from the top, and the end of the steam heat recovery and utilization, is a new type high efficient
energy- saving drying equipment.
4. New industrial food rotary dryer is based on over 28 years' experience, independent
of the development and production of a new type of high efficiency energy - saving drying
equipment.
5. Industrial food rotary dryer uses heat pipe indirect to materials heating, materials and
heat source to full contact, steam to real- time from the top of device , heat source use hot
-blast stove heating not consumption, with dry effect good, and structure reasonable, and
output big, and energy consumption low, and install convenient, and operation simple, and
to range wide such as advantage of, is feed such as powder materials the most ideal private
device.
Features of industrial food rotary dryer
1. Within the device is composed of dozens to hundreds of heat pipes materials enter
from the top of the heating duct fell after drying the bottom of the device,get to the bottom
will be hot after shave plate scraped the bottom of the tube material keeps contact with
heat pipe to have a drying effect. This can greatly improve thermal contact area and
utilization of the material.
2. The device has wet discharging device in the drying process can be a result of discharge
large amounts of water vapor in the first time, the complete separation of water vapor drying
faster the lower heat loss, because it avoids the material in the process of drying and water
vapour exposure to eliminate the material may not be caused by repeated drying of moisture
absorption.
3.Tail of air circulator,we can heat reuse of tail up into a dryer really do make full use of heat
to achieve energy - saving effect.
Raw material of industrial food rotary dryer
1) Wood sawdust, wood chip, wood shavings, etc.
2) Coal powder, coal slurry, coal waste, etc.
3) Clay, slurry, sand, silica sand, etc.
4) Grain, such as wheat, rice, etc.
5) Mash, diatillers, etc.
6) Animal dungs.
Structure of industrial food rotary dryer
Industrial food rotary dryer consists of seven parts: they are feeding hopper, heat source,
rotary drum, lifting board, draught fan, unloader.
Features of industrial food rotary dryer
1. Large production capability, continuous operation
2. Simple structure, convenient operation
3. Low malfunction, low maintenance cost.
4. Wide scope of application, can be used to dry the granular materials, favorable for those
materials with the big adhesion.
5. Great operating flexibility, the output of the products allows a larger fluctuation range, not
influencing the quality of the products.
6. High thermal efficiency(≥ 60%)
7. Medium temperature in outlets(about700 degree)
8. Alloy steel plate or stainless lifting plate
9. Guaranteed drying effect (≤ 5% after drying)
10. Final wood sawdust's humidity can be adjusted by adjusting its speed.
11. Far-ranging raw material: such as wood sawdust, wet sand, clay, coal, etc.
Main parameter of industrial food rotary dryer
Type |
Dia. of Roller (mm) |
Length of Roller (m) |
Rolling Speed (r/min) |
Motor Power(kw) |
Cubage (m ³ ) |
Weight (t) |
Φ 0.6*8 |
Φ 600 |
8 |
8 |
4 |
2.26 |
5.1 |
Φ0.8*10 |
Φ 800 |
10 |
7.2 |
4 |
5.02 |
6.9 |
Φ1.0*10 |
Φ 1000 |
10 |
6.73 |
5.5 |
7.85 |
7.5 |
Φ1.2*12 |
Φ 1200 |
12 |
5.8 |
11 |
13.31 |
13.1 |
Φ1.5*12 |
Φ 1500 |
12 |
4.8 |
15 |
21.2 |
22.3 |
Φ 18*14 |
Φ 1800 |
14 |
3.2 |
30 |
48.22 |
45.8 |
Φ2.2*18 |
Φ 2200 |
18 |
3 |
37 |
70.43 |
50.3 |
Φ2.4*20 |
Φ 2400 |
20 |
2.83 |
45 |
90.43 |
78.4 |
Φ2.8*24 |
Φ 2800 |
24 |
2.59 |
75 |
147.8 |
97 |
Φ3.0*20 |
Φ 3000 |
20 |
2.6 |
55 |
141.3 |
102 |
Φ3.0*25 |
Φ 3000 |
25 |
2.6 |
75 |
176.7 |
110 |
Customers came to our factory to check our industrial food rotary dryer
Delivery site of industrial food rotary dryer
Installation of industrial food rotary dryer
♣ Fireplace is the place where the firewood, coal, gas or other material is burning for heat,
there is a specially designed buffer which can make the hot air through but provent the fire
in.
♣ Inlet place is beside the fireplace, thus the material can be dry at a early time.
♣ Roller is running evenly to make the material drying and processing at the same time.
♣ Discharging unit is installed with thermeter to control drying temperature. Temperature
change of dryer's feeding end can be indicated by the thermometer to control the inner drier
temperature ( generally 250-350°C)
♣ The cyclone is for the discharging, whcih is more convenient and air lock for making the
discharging little noise and no waste.
If you are interested in our industrial food rotary dryer, please contact:
In order to provide you the most suitable industrial food rotary dryer, could
you share me the following details? Thanks!
1) What's your raw material?
2) How many kilograms raw material do you want to dry up per hour?
3) What's your raw material's dimension?
Our factory:
FAQ of industrial food rotary dryer
1. What the industrial food rotary dryer can be used for ?
Industrial food rotary dryer can dry many kinds of granules materials which contain moisture,
such as corn, grain, coal, coal slurry, slag, industrial waste, clay, sand, cow dung, chicken
dung, grain, etc. They are widely used in building materials, metallurgy, chemical industry.
2. Is the industrial food rotary dryer's heating source directly contact with clay?
Industrial food rotary dryer's heating source can provide about 700-800℃, so it will be very
dangerous if hot air directly contact the dry raw material. In order to avoide this, our industrial
food rotary dryer has designed a special equipment to avoide hot spark enters into rotary drum.
3. Can I use the coal or gas as the heating source?
Yes, you can use coal, gas, electricity, oil and wind power to heat the industrial food rotary dryer.
