Help CenterPlastic Film Slitting Machine
Related Products
Application:
To divide and cut rolls of plastic film (especially for PTFE) into pieces and then rewind them.
Features:
1) Scissors and round blade which are selected, easy to adjust the cutting width
2) Tensility can be controlled automatically with magnetic powder arrester
3) Let-off with photoelectric edge position controller (high precision)
4) Handwheel adjusts the takeup unit around both sides of base materials and the tightness of cloth is adjustable
5) Can stop automatically with figure displaying meter and yard
6) The main drive gears adopt electric decelerator machine, controlling the speed by frequency conversion
7) Keyset air expanding shaft adopted in roll-up and let-off
8) Double-axis alternative. Never biting with magnetic powder arrester, and speed-gap settings
9) Stable armor plate structure frame
10) The surface is sprayed with plastic, clean and beautiful, and easy to maintain
Main specification:
Item |
Parameters |
|
Max. slitting width (mm) |
600 |
900 |
Min. width of the slitting strips (mm) |
≥ 9 |
|
Max. unwinding diameter (mm) |
500 |
|
Max. rewinding diameter (mm) |
150 |
|
Designed speed(m/min) |
5~30 |
|
Power supply( kw ) |
3 |
4.5 |
Dimensions (L×W×H cm) |
140×100×120(not include control table) |
170×100×120(not include control table) |
Weight (kg) |
600 |
800 |
FAQ:
1.Q: Are you a factory or trading company?
A:We are a factory and manufacturer.
2.Q: Where is your factory located? How can I visit there?
A:Our factory is located in BaoShan District,Shanghai, China. You can fly to Shanghai Pudong airport directly. All our clients, from home or abroad, are warmly welcome to visit us!
3.Q: Could you send me your samples?
A: We are honored to receive your samples for Slitting or Laminating test ,then send to you back.
4.Q:How does your factory do regarding quality control?
A:"Quality is priority. YIMAI people always attach great importance to quality controlling from the very beginning to the very end.
