Help CenterLarge Laminating Machine
Related Products
Application:
Suitable for auto industry, non-woven fabrics, water-based adhesive padding or hot melt adhesive powder transfer composite roll.
Features:
1.A, B center unwind frame, with photoelectric edge position controller.
2.Water based adhesive padding cylinder, pressure adjustable.
3.Scattering consisted by engraved roller, brush, vibration bolt, mix device.
4.Heat sealing dry oven, three phase adjust pressure module, PID temperature control.
5.Built-in type heat roller, three phase adjust pressure module, PID temperature control.
6.According need to use air pressure type circular knife to cut edge or middle incision.
7.Rub rewind, fabric elasticity can be adjust.
8.Frequency conversion control, with synchronizer.
9.Frame steel structure, side with cover pieces, surface spray with plastic.
Main specification:
Item |
Parameters |
|
Roller width(mm) |
2000 |
2500 |
Max diameter of unwind and rewind(mm) |
1000 |
|
Design speed (m/min) |
5~30 |
|
FAQ:
1.Q: Are you a factory or trading company?
A:We are a factory and manufacturer.
2.Q: Where is your factory located? How can I visit there?
A:Our factory is located in BaoShan District,Shanghai, China. You can fly to Shanghai Pudong airport directly. All our clients, from home or abroad, are warmly welcome to visit us!
3.Q: Could you send me your samples?
A: We are honored to receive your samples for Slitting or Laminating test ,then send to you back.
4.Q:How does your factory do regarding quality control?
A:"Quality is priority. YIMAI people always attach great importance to quality controlling from the very beginning to the very end.
