Home > Packaging & Printing > Post-Press Equipment > Die Cutting Machine > YM93 Unwind Loading Device

YM93 Unwind Loading Device

Name: YM93 Unwind Loading Device
Brand: YIMAI
SKU: 126348141
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Condition:

New

Type:

Other, Unwind device

Place of Origin:

Shanghai, China

Contact Supplier Request Quote Chat Now

Shanghai Yimai Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Other, Unwind device

Place of Origin Shanghai, China

Brand Name YIMAI

Model Number YM93

Voltage 110~380V

After-sales Service Provided Engineers available to service machinery overseas

Application:

This unwinder device apply to unwind continues roll of paper, plastic film, aluminum foil and insulated material, which is the ideal assembled settings for slitting machine and coating machine.

Feature

1. Compact structure, higher mechanization, large load capacity, flexible function.

2. Each mechanical arm fix one flange type air shaft to ensure the same angle of arms. The shaft connected with two arms is driven by two motors which could turn on only one or both, so material is loaded easily to reduce intensity of labour.

3. Large torque, magnetic powder and automatic tension control system ensure simply operation.

4. Automatic axis set up.

5 Use section steel, plastic spraying on the frame.

Main technical parameter

Item	Parameters
Max. width(mm)	1000	1300	1600	2100
Rewind width(mm)	600			1100
Max. unwind Diameter(mm)	1200
Material Weightkg	1000
Max. rewinding diameter (mm)	600
Diameter of Core mm	76mm (3)
Dimensions L×W×H cm	310×110×100	310×140×100	310×170×100	310×220×100
Weightkg	1000	1200	1400	1700
