T series contour cutting plotter Hanze TH-1600
Usage
The machine with high speed and low noise . With the name speed in curve line and straight line.
Carving pressure and and quick separation .Standard DM/PL language pattern,with a high speed.
It canbe typed through CORELDAW directly.
CUTTING PLOTTER the main purposes is stuck in the fragile text or graphics. Forte by the dorsal surface and lining two materials, mouse, only in the exclusive bits stuck on the surface dielectric creates text or graphics,
while not cut back lining .And you can draw, cut, kiss-cut and decupe shapes around.
You can cut cartoon or other Vinyl and polyester sheets for your business and hobbies.
Features
1.Support coreldraw and Ai software outputting directly
2.Made of imported steel axis,have higher precision
3.More interface:USB/Serial port/U disk--can work offline
4.Compatible with Wifi and bluetooth function,can work without cable connection
5.3.0 inch Touch screen with sililcon buttons,operating more conwenient
6.OEM supplier for many famous brands
7.Huge pressure,cutting force can be 1000g if you need
| Model | TH-1600 |
| Media way | Floor stand |
| Control panel | 11 membrane buttons+3.0 inch touch screen |
| Driver | High speed,big power step motor,micro-step driver |
| Media size | 1600mm |
| Cutting size | 1550mm |
| Cutting speed | 550mm/s |
| Cutting force | 0-500g(it can be 1000g if you need) |
| Precision | 0.025mm |
| Type of plotter pen | All types diameter 11.4mm plotter pen |
| Plotter instruction | DM/PL,HP/GL automitic |
| Power supply | 110v-220v,50HZ |
| Interface | USB/U disk/Serial port/Wifi |
| Power consumption | <80w |
| Repeat function | 1-500 times |
| Knife(blade) | Imported blade |
| Operating environment | 5-35℃,Humidity:30%-70% |
| Package size | 1790*330*395mm |
| Gross weight | 55kg |
| Mainboard | 32-bit ARM CPU,4MB CATCH memory |
Cutting products show:
Excellent After-sale Services:
One year warranty |
You can discuss operation and maintenance with our technician online support service by Skype, MSN etc. Remote control will be provided upon request. |
Free exchange of new components |
Our quality is guaranteed 100%, the spare parts can be replaced within one year free of charge, you only need to pay the freight , except for the print head and some consumable parts. |
Free online consultation |
The technician will keep online. No matter what kind of technical questions that you may have, you would get a satisfactory answer from our professional technician easily. |
Free onsite installation and training |
If you are able to help us with getting the visa and also would like to bear the costs involved like flight tickets, food, etc, we can send our technician to your office, and to give you a free installation and training for as long as you know how to operate it |
