7 inch waterproof lcd rear view monitor
7 inch waterproof monitor :
• Waterproof resistant: IP66.
• Picture image may be adjusted for Horizontal, Vertical, Mirror and Normal viewing, menu characters won’t be reversed when mirror image is set
• 8 languages available to select
• Automatic backlighting for screen, automatic adjust to the brightness of environment
• System format: NTSC/PAL/AUTO
• four cameras with trigger lines, when the camera is triggered, the picture switches to the triggered camera automatically
• Auto scan, scan channel and time can be set according to user’s need
• Reverse warning yardstick, can be adjusted up and down, left and right
• Easy installation and convenient use, with innovative functions.
• Can be used both in vehicle, shipment surveillance and security monitor in the open air
• 13Pin: Up to 3 AV inputs. Three cameras input on the rear and one A/V input on the front panel.
• 22Pin: Up to 4 AV inputs, 1 video output and 1 audio output.
7’’ Digital Waterproof Monitor
• LCD size:7’’
• loudspeaker: 1W/8Ω
• Power supply: 10V~32V
• Energy consumption: max. 6W
• Outer dimension: 197.2mm (W) x 132mm(H) x 30.5mm(T).
• Resolution: 800 x 3(RGB) x 480
• Contrast: 500: 1
• Brightness: 400cd/m²
• Viewing angle: U: 50°, D: 70°, R/L: 70°
• Aspect ratio: 16: 9 / 4: 3
• Operating temperature: -20 ~ +70 °C RH90%
• Storage temperature: -30 ~ +80 °C RH90%
Testing Standard: MIL-STD-105E
Tests
Manufacturing Process
Tests
FAQ
Q: What is the MOQ ?
A: 1 peice
Q: How fast for sample delivery?
A: 3-7 days
Q: Can I get a lower price if I order large quantities?
A: Yes, the larger the quantity, the cheaper the prices.
Q: How about the warranty period?
A: One year!
Q: How can you guarantee the quality?
A: Our production quality follows the standard of MIL-STD-105E. We have a QC team with 12 years’ experience. All of the products will run through over 4 times’ 100% testing before being delivered.
