698 - 2700 MHz Logarithmic Periodic DAS Antenna
AMXL-7027-11
Feature:
Exquisite appearance
Good defense ability
Impact resistance, waterproofing, anticorrosion, etc.
Optimized dimension
Designed with Broadband technology.
Medium gain, low VSWR
Application:
GSM/ CDMA/ PCS/ 3G/ 4G/ LTE/ WLAN/ Wi-Fi system
|
AMXL-7027-11 Electrical Specifications | |
Frequency range(MHz) |
698~960/1710~2700 |
Bandwidth(MHz) |
262/990 |
Gain(dBi) |
10/11 |
Half-power beam width(°) |
H:65/50 V:55/40 |
VSWR |
≤1.8 |
Input Impedance(Ω) |
50 |
Polarization |
Vertical |
Maximum input power(W) |
50 |
Lightning protection |
DC Ground |
Input connector type |
N Female |
Mechanical Specifications | |
Dimensions (mm) |
445*210*65 |
Antenna weight(kg) |
0.91 |
Operating temperature(°c) |
-40~60 |
Rated Wind Velocity(m/s) |
60 |
Radome material |
ABS |
Radome color |
white |
Waterproof Standard |
IP54/ IP65/ IP67 |
Mounting way |
wall-hanging or pole-holding |
Mounting hardware(mm) |
35-50 |
