Attention:
As Ameison have more than 600 models antennas in our factory, in order to offer the optimum models and reasonable prices, please kindly let us know the frequency range, gain, connector style and cable length(if available), and if here this showed model is your required, that can be the best thus we can respond directly.
And please let us know whether your antenna should pass 3rd intermodulation LOW PIM(IM3) standard OR common standard, that is there have different relevant prices between them.
11dbi dual band 698 - 2700 MHz Logarithmic Periodic DAS Antenna for wireless network 3g 4g tablet pc wifi antenna
AMXL-7027-11
Feature:
Exquisite appearance
Good defense ability
Impact resistance, waterproofing, anticorrosion, etc.
Optimized dimension
Designed with Broadband technology.
Medium gain, low VSWR
Application:
GSM/ CDMA/ PCS/ 3G/ 4G/ LTE/ WLAN/ Wi-Fi system
|
AMXL-7027-11 Electrical Specifications | |
Frequency range(MHz) |
698~960/1710~2700 |
Bandwidth(MHz) |
262/990 |
Gain(dBi) |
10/11 |
Half-power beam width(°) |
H:65/50 V:55/40 |
VSWR |
≤1.8 |
Input Impedance(Ω) |
50 |
Polarization |
Vertical |
Maximum input power(W) |
50 |
Lightning protection |
DC Ground |
Input connector type |
N Female |
Mechanical Specifications | |
Dimensions (mm) |
445*210*65 |
Antenna weight(kg) |
0.91 |
Operating temperature(°c) |
-40~60 |
Rated Wind Velocity(m/s) |
60 |
Radome material |
ABS |
Radome color |
white |
Waterproof Standard |
IP54/ IP65/ IP67 |
Mounting way |
wall-hanging or pole-holding |
Mounting hardware(mm) |
35 - 50 |
