Help Center9dbi Dual Band 698-2700 MHz Logarithmic Periodic DAS Antenna 3g 4g Lte Cell Phone Signal Booster Wifi Wireless Internet Antenna
Related Products
-
18dbi 2400 - 2483 MHz Directional Yagi Wifi Repeater Antenna Tablet Android External Antenna High db Wifi AntennaNegotiableMOQ: 100 Pieces -
16dbi 2400 - 2483 MHz Directional Yagi Antenna High Gain cb Antenna Wireless Internet Antenna Wifi Antenna for TabletNegotiableMOQ: 100 Pieces
-
13dbi 2400 - 2483MHz Directional Yagi Antenna 2.4ghz Wifi Antenna Wireless Network AntennaNegotiableMOQ: 100 Pieces
-
16dbi Wide Band 2300 - 2700 MHz Directional Yagi Antenna 4g Lte Antenna Outdoor Bluetooth Wifi Antenna for Wireless NetworkNegotiableMOQ: 100 Pieces
-
15dbi 1850-1990MHz Directional Yagi Antenna Wireless Outdoor Antenna for Communications Cellular Signal BoosterNegotiableMOQ: 100 Pieces
Attention:
As Ameison have more than 600 models antennas in our factory, in order to offer the optimum models and reasonable prices, please kindly let us know the frequency range, gain, connector style and cable length(if available), and if here this showed model is your required, that can be the best thus we can respond directly.
And please let us know whether your antenna should pass 3rd intermodulation LOW PIM(IM3) standard OR common standard, that is there have different relevant prices between them.
9dbi dual band 698-2700 MHz Logarithmic Periodic DAS Antenna 3g 4g lte cell phone signal booster wifi wireless internet antenna
AMXL-7027-9
Feature:
Exquisite appearance
good defense ability
Impact resistance, waterproofing, anticorrosion, etc
Optimized dimension
Designed with Broadband technology
Medium gain, low VSWR
Application:
GSM/ CDMA/ PCS/ 3G/ 4G/ LTE/ WLAN/ Wi-Fi system
|
AMXL-7027-9 Electrical Specifications | |
Frequency range(MHz) |
698~960/1710~2700 |
Bandwidth(MHz) |
262/990 |
Gain(dBi) |
8/9 |
Half-power beam width(°) |
H:90/70 V:60/55 |
VSWR |
≤1.8 |
Input Impedance(Ω) |
50 |
Polarization |
Vertical |
Maximum input power(W) |
50 |
Lightning protection |
DC Ground |
Input connector type |
N Female |
Mechanical Specifications | |
Dimensions (mm) |
295*205*65 |
Antenna weight(kg) |
0.75 |
Operating temperature(°c) |
-40~60 |
Rated Wind Velocity(m/s) |
60 |
Radome material |
ABS |
Radome color |
white |
Waterproof Standard |
IP54/ IP65/ IP67 |
Mounting way |
wall-hanging or pole-holding |
Mounting hardware(mm) |
35 - 50 |
Send Inquiry to This Supplier
