AMEISON Hight Gain Anodized Alu 3g Yagi Antenna 18dbi

Name: AMEISON Hight Gain Anodized Alu 3g Yagi Antenna 18dbi
Brand: AMEISON
SKU: 126223085

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

AMEISON

Model Number:

AMXY-1722-18

Shenzhen Ameison Communication Equipment Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen or HongKong

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name AMEISON

Model Number AMXY-1722-18

AMEISON hight gain anodized alu 3g yagi antenna 18dbi

AMXY-1722-18

Feature:

High gain

Heavy-duty Anodized Aluminum alloy framework

Full day working

Optimized dimension

Vertical or Horizontal

Application:

3g LTE system

Point-to-point, point-to-multipoint system

Wireless bridging, client terminal antennas

AMXY-1722-18 Electrical Specifications
Frequency range(MHz)	1700-2170
Bandwidth(MHz)	470
Gain(dBi)	18
Element(s)	18
Half-power beam width(°)	H:35 V:30
Front-to-back ratio(dB)	≥16
V.S.W.R.	≤1.8
Input Impedance(Ω)	50
Polarization	Horizontal or Vertical
Maximum input power(W)	100
Lightning protection	DC Ground
Input connector type	N-Female or Requested
Mechanical Specifications
Dimensions(mm)	78011044
Cable length(m)	0.3
Antenna weight(kg)	0.4
Operating temperature(°c)	-40~60
Rated Wind Velocity(m/s)	60
Clamp	U-shape
Mounting hardware(mm)	35~50
