Antenna Manufacturer 1920-2170MHz 3dBi Wave Blade Microstrip 3g car Patch Antenna

Name: Antenna Manufacturer 1920-2170MHz 3dBi Wave Blade Microstrip 3g car Patch Antenna
Brand: AMEISON
Price: Negotiable

FOB Price

Negotiable / Piece

2000 Pieces(Min.Order)

Supply Ability 2 Piece / Pieces per Month
Port Shenzhen or HongKong
Payment Terms:T/T Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:

Guangdong, China

Brand Name:

AMEISON

Model Number:

AMXS-1922-3

Packaging Details

bubble PP bag or EPE/inner box/master carton(safe export packaging) or others

Product Description

Specifications

Wireless antenna is well suited for all your 1.9-2.1GHz Personal Communication Service (PCS) and Cellular Data Band Application.

The compact size of this antenna is ideal where Omni-directional coverage and low visibility are desired.

Mobile applications, including service vehicles, public transportation, law enforcement, mining and construction vehicles, as well a numerous other commercial and industrial applications where mobility is required, can be serviced with this antenna.

The foam double sided tape provides a secure and reliable mounting mechanism allowing deployment in many places. The 3-meter RG174 cable provides the user with flexible options where to place the antenna.

3ghz patch antenna car antenna

Factory price

Antenna gain is 3 dBi

Beautifull appearance

1920-2170MHz Patch Antenna

AMXS-1922-3

Feature:

High gain

Superior performance

Strong anti-interference ability

Full day working

Exquisite appearance

Optimized dimension

Mounting foam tape backing system with attached 3-Meter cable

Indoor or Outdoor use

RoHS Compliant

Application:

For vehicle alarm

Vehicle mobile communication device

PCS cellular radio applications

UMTS, GSM, G3, ISM, WLAN, RFID applications

Mobile Applications

Low profile mounting-stick on Foam Tape

Remote antenna location for better reception

AMXS-1922-3 Electrical Specifications
Frequency range(MHz)	1920-2170
Bandwidth (MHz)	250
Gain (dBi)	3
VSWR	≤2.0
Input Impedance(Ω)	50
Polarization	Vertical
Maximum input power(W)	50
Input connector type	SMA Male or Requested
Mechanical Specifications
Dimensions(mm)	115*21
Antenna weight(g)	30
Mounting way	Stick
Operating temperature(°c)	-40~60
