Ameison 2.4G (lightning Protector)surge Arrester
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
AMEISON
Model Number:
AMXB-2400
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen or HongKong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
N-male to N-Female Bulkhead 2.4GHz 230V High Performance Lightning Protector Lightning ArrestorNegotiableMOQ: 50 Pieces -
5.8G Lightning Arrester(lightning Protector)NegotiableMOQ: 100 Pieces
-
N-male to N-Female Bulkhead 2.4GHz 230V High Performance Lightning Protector Lightning Arrester Surge ArresterNegotiableMOQ: 50 Pieces
-
N-male to N-Female Bulkhead 5.8GHz 230V High Performance Lightning ProtectorNegotiableMOQ: 50 Pieces
-
2.4G Lightning Arrester(lightning Protector)NegotiableMOQ: 100 Pieces
Place of Origin
Guangdong, China
Brand Name
AMEISON
Model Number
AMXB-2400
2.4G Lightning Arrester(lightning protector)
Model:AMXB-2400
Product name:N discharge tube surge arrester
Technical indicators Specification:
Impedance(Ω) |
50 |
|
Contact resistance( MΩ) |
Inner conductor(MΩ) |
≤0.4 |
Outer conductor(MΩ) |
≤0.2 |
|
Insulation Resistance (MΩ) |
≥1x104 |
|
Pressure AC(V min) |
4000V 1min No breakdown and no arcing phenomenon |
|
Frequency Range(MHz) |
DC~2500 |
|
V.S.W.R(MHz) |
≤1.20 |
|
Insertion Loss(dB) |
≤0.2 |
|
Rated Power(W) |
200 |
|
Initial discharge voltage(V) |
230 |
|
Peak discharge voltage(V(1×40μS)) |
1000 |
|
Peak discharge current(KA) |
20 |
|
Weight(g) |
125 |
|
