2500-2700 MHz Omnidirectional Fiberglass Antenna
AMXF-2527-10
Feature:
Exquisite appearance
Good impact resistance,waterproofing and anticorrosion ability
Full day working
Optimized dimension
High gain,low standing wave,strong anti-interference ability
Application:
4g, LTE system
Point-to-multipoint system
|
AMXF-2527-10 Electrical Specifications | |
Frequency range(MHz) |
2500~2700 |
Bandwidth(MHz) |
200 |
Gain(dBi) |
10 |
Half-power beam width(°) |
H:360 V:10 |
VSWR |
≤1.5 |
Input Impedance(Ω) |
50 |
Polarization |
Vertical, Linear |
Maximum input power(W) |
100 |
Lightning protection |
DC Ground |
Input connector type |
N Female or Requested |
Mechanical Specifications | |
Dimensions (mm) |
Φ20*770 |
Antenna weight(kg) |
0.45 |
Operating temperature(°c) |
-40~60 |
Rated Wind Velocity(m/s) |
60 |
Radome color |
Gray or White or others |
Radome Material |
Fiberglass |
Waterproof Standard |
IP65/ IP67 |
Mounting way |
Wall/ Pole-holding |
Mounting hardware(mm) |
35-50 |
After-sale service:
1)All of our product will have been strictly test before packing
2)All of our product will be well packed before shipping
3)All of our prodect will have one year quality warranty, free maintenance with warranty period!
OEM/ODM ORDERS ARE WELCOMED BY US.
