UHF 450 MHz 5dB Outdoor/indoor Omnidirectional Fiberglass Walkie Talkie Antenna

Name: UHF 450 MHz 5dB Outdoor/indoor Omnidirectional Fiberglass Walkie Talkie Antenna
Brand: AMEISON
SKU: 126222433

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

AMEISON

Model Number:

AMXF-450-5

Shenzhen Ameison Communication Equipment Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen or HongKong

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name AMEISON

Model Number AMXF-450-5

450 MHz Omnidirectional Fiberglass Antenna

AMXF-450-5

Feature:

Exquisite appearance

Good impact resistance,waterproofing and anticorrosion ability

Full day working

Optimized dimension

High gain,low standing wave,strong anti-interference ability

Application:

450 MHz system

Point-to-multipoint system

AMXF-450-5 Electrical Specifications
Frequency range(MHz)	450-470
Bandwidth(MHz)	20
Gain(dBi)	5
Half-power beam width(°)	H:360 V:30
VSWR	≤1.5
Input Impedance(Ω)	50
Polarization	Vertical, Linear
Maximum input power(W)	100
Lightning protection	DC Ground
Input connector type	N Female or Requested
Mechanical Specifications
Dimensions (mm)	Φ20*1100
Antenna weight(kg)	0.55
Operating temperature(°c)	-40~60
Rated Wind Velocity(m/s)	60
Radome color	Gray or White or others
Radome Material	Fiberglass
Waterproof Standard	IP65/ IP67
Mounting way	Wall/ Pole-holding
Mounting hardware(mm)	35-50
