AMEISON 136-174 MHz Omni Fiberglass 5 DBi Ais Vhf Antenna

Name: AMEISON 136-174 MHz Omni Fiberglass 5 DBi Ais Vhf Antenna
Brand: AMEISON
SKU: 126222327
Availability: InStock

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

AMEISON

Model Number:

AMXF-155-5

Shenzhen Ameison Communication Equipment Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen or HongKong

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name AMEISON

Model Number AMXF-155-5

AMEISON 136-174 MHz omni fiberglass 5 dBi ais vhf antenna

AMXF-155-5

Feature:

Exquisite appearance

Good impact resistance, waterproofing and anticorrosion ability

Full day working

Optimized dimension

High gain, low standing wave, strong anti-interference ability

Application:

136 - 174 MHz system

Point-to-multipoint system

AMXF-155-5 Electrical Specifications
Frequency range(MHz)	136-174
Bandwidth(MHz)	12
Gain(dBi)	5
Half-power beam width(°)	H:360 V:55
VSWR	≤1.5
Input Impedance(Ω)	50
Polarization	Vertical, Linear
Maximum input power(W)	100
Lightning protection	DC Ground
Input connector type	N Female or Requested
Mechanical Specifications
Dimensions(mm)	Φ20*1550
Antenna weight(kg)	0.65
Operating temperature(°c)	-40~60
Rated Wind Velocity(m/s)	60
Radome color	Gray or White or others
Radome Material	Fiberglass
Waterproof Standard	IP65/ IP67
Mounting way	Wall/ Pole-holding
Mounting hardware(mm)	35 - 50
