Help Center1920-2170MHz 16dBi Heavy-duty Extruded Anodized Aluminum 3g Yagi Antenna
Related Products
-
698-960MHz 15dBi 90 Degree Vertical Polarized Sector Panel GSM AntennaNegotiableMOQ: 500 Pieces -
5725-5850MHz(5.8GHz) 23dBi High Gain Directional Flat Panel Wireless AntennaNegotiableMOQ: 500 Pieces
-
Outdoor/Indoor 2400 - 2483MHz (2.4GHz)18dBi Directional Flat Patch Panel Wifi AntennaNegotiableMOQ: 500 Pieces
-
Outdoor/Indoor 1710-2170MHz 14dBi High Gain Wall Mount Flat Patch Panel PCS 3g AntennaNegotiableMOQ: 500 Pieces
-
6dBi Directional Wall Mount Flat Panel 433MHz AntennaNegotiableMOQ: 500 Pieces
Specifications
3g wireless Yagi antennas are well suited for all your Personal Communication Service (PCS),Cellular, LTE applications.It is ideally suited for directional and multipoint 1.9 MHz band applications such as Personal Communication Services (PCS) and 1.9GHz cellular band applications.
1.9 GHz band applications
Personal Communication Service (PCS)
Directional and multipoint applications
1920 - 2170 MHz band applications
Cellular, LTE
3g 16 dBi heavy-duty extruded anodized Aluminum Yagi Antenna-N Female or other connector specifications
Feature:
High gain;
Extruded anodized Aluminum Alloy framework;
Full day working;Optimized dimension;
Vertical or horizontal mounting way.
Application:
3GHz system;
Point-to-point, point-to-multipoint system;
Wireless bridging, client termination antenna.
|
AMXY-1922-16 Electrical Specifications | |
Frequency range(MHz) |
1920-2170 |
Bandwidth(MHz) |
250 |
Gain(dBi) |
16 |
Element |
15 |
Half-power beam width(°) |
H:35 V:30 |
Front-to-back ratio(dB) |
≥16 |
VSWR |
≤2.0 |
Input Impedance(Ω) |
50 |
Polarization |
Horizontal or Vertical |
Maximum input power(W) |
100 |
Lightning protection |
DC Ground |
Input connector type |
N female or others |
Mechanical Specifications | |
Dimensions(mm) |
610*84*44 |
Cable length(m) |
0.3 |
Antenna weight(kg) |
0.36 |
Operating temperature(°c) |
-40~60 |
Rated Wind Velocity(m/s) |
60 |
Clamp |
U-shape |
Mounting hardware(mm) |
Φ35~Φ50 |
