UAV Communication, digital communication, public security dispatching, emergency communications and other fields
(1) small size image transmission, high power image transmission
(2) operating frequency range : 260MHz~1G
(3) output power : 0.5W~20W range
(4) modulation type: COFDM, QPSK, DVB-T, etc.
(5) Customizable power adjustable
(6) small size
(7) High cost performance
(8) mainly used in the field of UAV Communication, digital communication, public security dispatching, emergency communications, etc.
Model |
Frequency (MHz) |
Out Power (W) |
Shoulder (dBc) |
Supply Voltage (V) |
Current (A) |
Signal type |
WS2001T1 |
260~300 |
1 |
≤ -39 |
12 |
≤0.55 |
COFDM,QPSK,DVB-T |
WS3004T1 |
300~310 |
4 |
≤ -36 |
12 |
≤0.9 |
COFDM,QPSK,DVB-T |
WS3020T1 |
300~310 |
20 |
≤ -37 |
27 |
≤2.8 |
COFDM,QPSK,DVB-T |
WS3004T2 |
330~350 |
4 |
≤ -36 |
12 |
≤1 |
COFDM,QPSK,DVB-T |
WS3020T2 |
330~350 |
20 |
≤ -37 |
27 |
≤2.8 |
COFDM,QPSK,DVB-T |
WS3004T3 |
390~400 |
4 |
≤ -36 |
12 |
≤1 |
COFDM,QPSK,DVB-T |
WS3020T3 |
390~400 |
20 |
≤ -36 |
27 |
≤2.8 |
COFDM,QPSK,DVB-T |
WS4001T2 |
470~520 |
1 |
≤ -37 |
12 |
≤0.5 |
COFDM,QPSK,DVB-T |
WS4004T2 |
470~520 |
4 |
≤ -37 |
12 |
≤0.9 |
COFDM,QPSK,DVB-T |
WS5001T0 |
490~570 |
1 |
≤ -39 |
12 |
≤0.5 |
COFDM,QPSK,DVB-T |
WS5001T3 |
560~600 |
1 |
≤ -37 |
12 |
≤0.5 |
COFDM,QPSK,DVB-T |
WS5004T3 |
560~600 |
4 |
≤ -36 |
12 |
≤0.9 |
COFDM,QPSK,DVB-T |
WS6004T2 |
660~680 |
4 |
≤ -36 |
12 |
≤0.9 |
COFDM,QPSK,DVB-T |
WS14004T1 |
1429~1525 |
4 |
≤ -36 |
27 |
≤2.8 |
COFDM,QPSK,DVB-T |
WS24004T1 |
2400~2500 |
4 |
≤ -36 |
12 |
≤2.8 |
COFDM,QPSK,DVB-T |
Other frequency range and output power is available for customization!
