5LL400 Gold Mining Gravity Spiral Chute
Description of Spiral Chute:
Beneficiation spiral chute is the technology product after years of accumulated experience from the development of beneficiation plant, is the best equipment for mining, beneficiation, especially waterfront, river, sand beach, creek road placer mining is more ideal. Product has reasonable structure, simple installation, small footprint, ease of operation, processing stability, sub-ore clear, large capacity, high efficiency characteristics. Products use special PVC plastic production, light weight, moistureproof, rust-proof, corrosion resistant, strong suitable for feeding ore quantity,particle size, grade fluctuations adaptability, no noise, etc.
Applications of Spiral Chute:
This device is suitable for sorting size 0.3 - 0.02 mm thin material of iron ore, ilmenite, chromite, pyrite, zircon, rutile, monazite, phosphorus B ore, tungsten ore, tin, tantalum ore, niobium ore as well as the proportion of differences and other nonferrous metals, rare metals and non-metallic mineral body.
This equipment has the stable sorting process, easy to control, to allow changes in ore concentration range, enrichment ratio, high recovery rate, small footprint, water consumption, simple structure, without power, large capacity, easy to install, easy operation, small investment and quick advantages.
| Model | 5LL-1500 | 5LL-1200 | 5LL-900 | 5LL-600 | 5LL-400 |
|---|---|---|---|---|---|
| outter dia(mm) | 1500 | 1200 | 900 | 600 | 400 |
| spiral distance(mm) | 540.720 | 900,720,540 | 675,540,405 | 450,360,270 | 240,180 |
| spiral distance ratio | 0.75,0.6,0.45 | 0.75,0.6,0.45 | 0.75,0.6,0.45 | 0.75,0.6,0.45 | 0.6,0.45 |
Gradient (°) |
9° | 9° | 9° | 9° | 9° |
| Number of threads | 4-2 | 4-2 | 4-2 | 3 | 2 |
| feeding size(mm) | 0.3-0.02 | 0.3-0.03 | 0.3-0.03 | 0.2-0.02 | 0.2-0.02 |
| Mine density (%) | 25-55 | 25-55 | 25-55 | 25-55 | 25-55 |
| capacity (t/h) | 8-6 | 4-6 | 2-3 | 0.8-1.2 | 0.15-0.2 |
| Outside diameter(mm) | 1560 | 1360 | 1060 | 700 | 460 |
| Heigh (mm) | 5230 | 5230 | 4000 | 2600 | 1500 |
Pre-sales Service:
1. The wide product range enables us to provide our customers with stand-alone machines or complete processing plants;
2. Based on our customers'request and budget, our experts make efficient, reliable solutions;
3. Before placing the order every customer has the chance to visit daiwo working machines or complete plant in the site;
4. We have a full set of testing equipment, to provide a good test environment.
After-sales Service:
1. Experienced technicians guidance and engineers will be dispatched to the quarry site to help install the customers'plants;
2. Provide necessary training about machine daily maintenance to local workers ;
3. After-sales department has well-trained employees and professional installation engineers.
Henan Baichy Machinery Equipment Co., Ltd. was founded in 2003, and now it has been becoming a high-tech mining company. Our company integrates research and development, designing, manufacturing, sales and after-sales services. The brand products, cone crusher, sand making machine, high-efficient fine crusher, high-pressure medium-speed mill, vertical mill, micronizer, three ring mill, ball mill, etc, are in the leading level of the world. Our company became the member of "CSSA Chinese gravel Association", and all the products have gained ISO9001: 2008 quality management system certificate and IQNet international certification.
