1. Professional |
15 years' rich experience! a.Specialized in Colored Metal Wall Sheet Roill Forming Machine for Sale since 1998; b.Keeping improving the quality. |
2. Low price |
Save your money from every part! a. Low labor cost; b. Convenient transportation; c. Complete supporting industries. |
3. PLC |
Ensuring high accuracy and easy to operate! Full Automatic: Just input length of the sheets and numbers of the piece you need, then the machine will start to work as your order. |
4. OEM / ODM |
Customers’design, color & logo are also accepted! Our specialized experts and skilled workers keep devoting their hard working to ensure the machine with high quality. |
5. TWO-Years warranty, whole life service |
Keep troubles far away from you! Within the TWO-YEARS period, we could supply you the replacement parts free of charge for any damaged parts caused by quality problems . |
2. Brief Introduction
a. General | |
| |
Model Number |
YX10-127-890 Colored Metal Wall Sheet Roill Forming Machine for Sale |
Suitable Material |
Q235 or equivalent, 0.3-0.6 mm thickness |
Material Width |
1000mm |
Wave Height |
10mm |
Covering Width |
890 mm |
Dimension |
about 5.7*1.3*1.1 m (L*W*H) |
Working Space |
about15.7*2.8 m (L*W) |
Length Of Sheet |
You can set the length according to your need, such as 1.5m, 3.2m or 6.7m. It is controlled by PLC, and can ensure the accuracy of ±1mm. |
| Cutting | Automatically stop and cutting when it comes to the set length |
Forming Speed |
0-15 m/min |
|
b. Components Details
| |
Roller Material |
High grade 45# steel. Treating process: finish turning-accurate grinding- polishing- hard chrome plating, 0.05 mm |
Main Frame |
350 H steel. More stable, no shaking |
Middle Plate |
16 mm. we use bigger plates, to ensure stability |
Shaft Material |
Φ70 mm, high grade 45# steel. Treating process: tempering- finish turning, high rigidity, hard to deform. |
Forming Steps |
13 |
Cutting Blade Material |
Cr12, hardness HRC60-62. Treating process: heat treatment- pane abrasion-wire electrode cutting |
|
c. Electric Components
| |
Suitable power |
380V, 50 Hz, 3 phase or according to your need. |
Screen |
5.7 inch touch screen, easy to operate |
PLC |
Delta DVP14ES, well-adapted to various conditions, such as moisture, electromagnetic disturbance. |
Frequency converter |
Delta VFD-M. It has the advantage of slowing down before cutting, to ensure the length accuracy (±1mm, far better than industrial standard ±3mm). |
Length measurement device: |
Omron, made in Japan. It features with high accuracy and stability |
a. TWO-Years product warranty.
b. Training and installation available
c. The technical support for the whole life
...
