1 2 Inch 7 Segment Led Display, One Digit Led Single Digital Led Display

US$ 0.1 - 0.9 MOQ: 1000 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Model Number:

JYL30012R-B10

Contact Supplier Request Quote Chat Now

Shenzhen Jinye Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name JY

Model Number JYL30012R-B10

Usage Indoor

Tube Chip Color Other, RED

Display Function Other, number

Pixels 20mm

Screen Dimension 14.0*7.5mm

Mode No: JYL30012R-B10

7 segment led display one digit

A.Digital led display used for clock number display

1.Electrical optical charactertistics(Ta25°C)

Parameter	Symbol	Min	Type	Max	Unit	Test Condition
Luminous Intensity	IV	165	182	185	mcd	IF=20mA
Peak Wavelength	λp				nm	IF=20mA
Dominant Wavelength	λd	510	511	512	nm	IF=20mA
Forward Voltage	Vf	3.0	3.2	3.5	V	IF=20mA
Reverse Current	IR			50	uA	VR=5V
Suggestion Forward Current	IF	3	5-10	20	mA	IF=20mA

2.Absolute Maximum Ratings (Ta=25°C):

Parameter	Rating	Unit
Reverse Voltage	5	V
Power Dissipation,Per Dice	50	mW/chip
Operating Temperature Ranger	-48~+85	°C
Storage Humidity	45%~85%	°F
Storage Temperature Ranger	-40~+90	°C
Soldering Temperature	260°C For 3 Seconds
Peak IF(ma) (1/10Duty Cycle 0.1ms Pulse Width)	100	mA/chip
Continuous Forward Current	20	mA/chip

B.Products show:

C.Products advantages:

1. long life according to technical experiments

2. High efficiency and tested by many customers

3. Sold state reliability

4. Luminous evenly distributed on each segment

5. Provides excellent reliability in bright ambient light

6. ISO9001-2008 ,SGSand ROHS certificate

7. Competitive price

8. Size and colors can be provided by your application

9. Chips sourced from Taiwan and America .
