double glass two-component coating machine
Introduction:
silicone sealing machine TCC300A is used to make insulating glass.
It can also be called in following names:
insulating glass machine, window glass making machine double glazed windows machine insulating glass , double glazed windows machine, insulated glass production machine, igu/dgu machine, triple glazing machine manufactures, double glazing line, double glazing machinery for sale, vertical insulating glass production line, double vitrage machine, insulated glass production machine, double glass machine, automatic insulating glass production line, glass washing machine, double glazed glass price machine, insulating glass production equipment, double glazing glass making machine
In addition to insulating glass machine, we also provide butyl extruder / coating machine, cnc glass cutting table / machine, silicone sealing machine robot / two component coating machine, dessicant filling machine, aluminum spacer bending machine, glass vacume lifter, etc.
Model: TCC300A
Features:
♦ This is a special purpose and machine spreading two-part polg sulfide sealant when making aluminum groove type insulating glass and curtain wall glass.
♦ The main and auxiliary pumps activated by hydraulic lubrication oil and compressed air, controlled by no-touch-point electric control system, is smooth to run, flexible and reliable to change direction, continuous and stable to produce sealant, high in efficiency and convenient to use and maintain, so it is one of the most important equipment to make aluminum groove type insulating glass and curtain glass.
♦ Most of the parts on the machines are imported.
Parameter:
♦ Voltage: |
380V 50HZ |
♦ Power: |
1.1KW |
♦ Air pressure: |
0.5-0.8Mpa |
♦ Air consumption: |
0.6L/min |
♦ A pump pressure plate size: |
Φ565 (50 gallon barrel) |
♦ B pump pressure plate size: |
Φ285 (5 gallon barrel) |
♦ Mixed rate: |
100:6.5-100:14.5 |
♦ Overall dimension: |
1100mm x 950mm x 1630mm |
♦ Weight: |
600kg |
♦ Glue type: |
SILICON,SULFIDE,URETHANE |
1.Sample service:
Engineer available overseas
2. Customized service:
Free industrial information, free investment analysis for windows, doors, and curtain wall project, free layout design for window, and door and curtain wall product line.
3.After sales service:
One year guarantee
Free adjustment
Free training to operation and maintenance workers
Provide quick supply of spare parts for window and curtain wall companies.
1. Q: Are you a factory or trading company?
A: We are a factory.
2. Q: Where is your factory located? Can I visit there?
Our factory is located in Jinan City, Shandong Province, China, near to Jinan and Qingdao. You are warmly welcomed to visit us!
3. Q: How does your factory do regarding quality control?
We have strict control in testing of raw material, production process and final process. Only qualified products can be sent out.And we have passed ISO,CE certificate.
4.Q:What you can do if my machines have problems?
a.We can send you free components to you if your machines are in guarantee time.
b.We can send our engineers to repair your machines
5. Q: If OEM available?
Answer: Yes, as we usually do.
6. Q: What are your company normal payment Terms?
Answer: We accept T/T (30% T/T prepaid before production, 70% T/T prepaid before shipment)
