High speed insulating glass machine production line
Insulating glass machine production line
Germanic technology is adopted in the whole line and main components are imported from world famous brand since it will be stable, convenient to maintain, and easy to handle Insulating glass like standard glass, overlength glass, coated glass, low-E glass, big and small glass, step glass, special shape glass, triple glass, etc can be produced
Features:
1.It can process double glazing glass, triple glazing glass, stepped glass and shaped glass.
2.Automatic distinguishing of Low-E glass and coating glass. Then the hard brush will step back lest film scratching.
3.It can produce insulating/glazing glass with the maximum of 2200*3000 mm, with the minimum of 250*450 mm.
4.Servo control system, screw tracked flat press ensures high precision in combination and steady work.
5.Colored touch screen for real time monitoring; self-diagnose system, easy to check the malfunction; online check available.
6.Laser-cut and CNC bending back board for high intensity and easy assembling.
7.Germany industrial plastic bearing is adopted in the glass cleaning section for rusty prevention.
8.Spacer installing support to realize adjustable sealant sealing in-depth.
9.Seamless connection to film remover and two-component coating machine can be realized.
10.Frequency converter to freely slow down or speed up for higher working efficiency.
Parameter:
Voltage: 380V 50Hz
Power: 24 kW
Air consumption: 160 L/min
Cleaning speed: 8~12 m/min
Maximum speed : 50 m/min
Max. process dimension: 2200* 3000mm
2200*3000 mm (under stepped press)
Min. process dimension : 250mm *480mm
Insulating glass thickness: 12~60 mm
Tilting angle : 485±50 mm 6°
Sealant in-depth :0~20 mm
Stepped glass dimension 0~50mm(H), 0~250 mm(L)
Pressing method Screw assembling
Overall dimension: 20000(L)*2800(W)* 3300(H) mm
Weight : 4800 kg
Insulating double glazing glass machine production line video link
/watch?v=UYN9cZvEOY0&index=2
insulating glass machine production line
Aluminum space bar bending machine
/watch?v=R6zjlty_0N0&index=6
Elevator and Automatic Molecular Sleve Filling Machine
/watch?v=w-UyGbhN1-0&index=4
Butyl Coating Machine
/watch?v=6MOgUj2N5yc&index=7
Rotary Coating machine insulating glass machine
/watch?v=knXex4NuboY&index=5
Vertical Glass Film Removing Machine AM22/25/27-A3
/watch?v=VhuCbUGK1ak&index=9
1.Sample service:
Engineer available overseas
2. Customized service:
Free industrial information, free investment analysis for windows, doors, and curtain wall project, free layout design for window, and door and curtain wall product line.
3.After sales service:
One year guarantee
Free adjustment
Free training to operation and maintenance workers
Provide quick supply of spare parts for window and curtain wall companies.
1. Q: Are you a factory or trading company?
A: We are a factory.
2. Q: Where is your factory located? Can I visit there?
Our factory is located in Jinan City, Shandong Province, China, near to Jinan and Qingdao. You are warmly welcomed to visit us!
3. Q: How does your factory do regarding quality control?
We have strict control in testing of raw material, production process and final process. Only qualified products can be sent out.And we have passed ISO,CE certificate.
4.Q:What you can do if my machines have problems?
a.We can send you free components to you if your machines are in guarantee time.
b.We can send our engineers to repair your machines
5. Q: If OEM available?
Answer: Yes, as we usually do.
6. Q: What are your company normal payment Terms?
Answer: We accept T/T (30% T/T prepaid before production, 70% T/T prepaid before shipment)
