Help CenterAluminum Window-door and Wall Curtain Processing Center DMCC82
Related Products
-
Aluminum Window-door and Wall Curtain Processing Center DMCC6US$ 50,000 - 100,000MOQ: 1 Set -
Automatic Window Curtain Wall Milling and Drilling Machine CenterNegotiableMOQ: 1 Unit
-
Parker Curtain Wall Drilling Milling Tapping Processing CenterNegotiableMOQ: 1 Volt
-
Cnc Aluminum Window Door Curtain Wall Machining CenterUS$ 1 - 2MOQ: 1 Set
-
PARKER Machining Center/cnc Aluminum Window Door Curtain Wall Machining CenterNegotiableMOQ: 1 Unit
Main feature:
1. The machine is suitable for processing installation holes, water slot,shaped holes, and end milling and making srew on curtain walls and aluminum windows and doors.
2.It adopts high-speed electric principal axis,which is imported from Italy.
3.It adopts high quality computer control system which is used in industry area specially,with good user interface, graphical programming and processing tracking interface,truly realize what you see and what you get.
4.It adopts high-quality servo motor,ball srew,linear guide pair and bearings and so on to ensure the machine with runs with high precision.
5.Equipped eight cutters positions, the cutter can change quickly and automatically.
6.Locating and processing with super speed which can be up to 120m/min.
7.Processing angle from +90° to -90°.
8.Half dry colling system,without toxin and pollution, and easy to clean.
9.Circular tube can be also be processed.
10.Single processing and circular processing can be set freely. And this improves efficiency.
11. Double-location is optional. This maching center can process two pieces of profiles at one time and lengthy profile.
| X axsis | 3500mm |
| Y axsis | 400mm |
| Z axsis | 400mm |
| X axis running speed | 0~100m/min |
| Y axis running speed | 0-80m/min |
| Z axis running speed | 0-60m/min |
| Cutter station | 8cutters ,automatic change by program |
| Air supply | 0.5-0.8Mpa |
| Voltage | 380V 50HZ |
| Total power | 13 kw |
| Clamp station | 4 |
| Lubrication and cooling | half dry coolling system |
| Positioning accuracy | ±0.02mm |
| Overall dimension | 5350mmx1800mmx2500mm |
| Cylindricity | ±0.01mm |
| Max. processing speed | 3000mm |
Founded in 2003, Parker Machinery Co., Ltd has developed an assembly line for door, window, curtain wall and insulating glass equipment. With over ten years' production experience, Parker has become a leading manufacturer of window door machinery in China. The operation of high precision, advancement and specialty ensure that we are able to supply high-quality window and door equipment for customers.
During the past few years, Parker has made great progress and has become well known and outstanding in domestic fairs for window door machinery. With advanced technological equipment, tremendous technical strength and reliable product quality, our window and door equipment has been well received by customers from Russian, Kazakhstan, Vietnam, Iran, etc. We have a perfect sales network and complete service system in China. We are also taking a leading role in setting branch companies abroad.
1.Sample service:
Engineer available overseas
2. Customized service:
Free industrial information, free investment analysis for windows, doors, and curtain wall project, free layout design for window, and door and curtain wall product line.
3.After sales service:
One year guarantee
Free adjustment
Free training to operation and maintenance workers
Provide quick supply of spare parts for window and curtain wall companies.
1. Q: Are you a factory or trading company?
A: We are a factory.
2. Q: Where is your factory located? Can I visit there?
Our factory is located in Jinan City, Shandong Province, China, near to Jinan and Qingdao. You are warmly welcomed to visit us!
3. Q: How does your factory do regarding quality control?
We have strict control in testing of raw material, production process and final process. Only qualified products can be sent out.And we have passed ISO,CE certificate.
4.Q:What you can do if my machines have problems?
a.We can send you free components to you if your machines are in guarantee time.
b.We can send our engineers to repair your machines
5. Q: If OEM available?
Answer: Yes, as we usually do.
6. Q: What are your company normal payment Terms?
Answer: We accept T/T (30% T/T prepaid before production, 70% T/T prepaid before shipment)
