Aluminum Profile Window Door Any Angle Double Head CNC Cutting Machine

Name: Aluminum Profile Window Door Any Angle Double Head CNC Cutting Machine
Brand: PARKER
SKU: 126027233

US$ 1 - 2 MOQ: 1 Unit

Key Specifications

Condition:

New

Type:

Other, electric

Application:

aluminum

Jinan Parker Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

FOB Qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, electric

Application aluminum

Place of Origin Shandong, China

Brand Name PARKER

Model Number A8-500

Rated Power 6.8KW

No-Load Rotational Speed 2800 R/min

Saw Blade Diameter 500mm

Max. Cutting Depth 300

Dimensions 6800mmX1500mmX2040mm

Voltage 380V

Power(W) 5.5kw

Certification CE Certificate

After-sales Service Provided Engineers available to service machinery overseas

aluminum Any Angle Double Head CNC Saw Cutting Machine

MachineModel: A8-500

Features:

The machine is the most advanced double-head cutting saw.
The control system adopts the new closed-loop system, and can ensure the accuracy of repeat length.
The PLC, servo motor, servo driver and touch screen we use the brand Schneider imported from France.
All the electric spare parts using Schneider imported for France.
This machine can automatically feed the profiles. Can input the cutting data one time. Automatic continuously different cutting size are available.
The imported blade (Wemaro imported from Germany) with high precision makes the cutting surface smoothly.
The servomotor drives the speed reducer to adjust the cutting angle in 45°-157.5°. The imported service motor with high moving speed and high precision should drive the sawing head.
The imported control system can ensure the cutting quality.
Touch screen and computer make the machine very easy to operate.
The machine has label printing function (option).

Parameter:

Voltage:	380V 50HZ
Power:	6.8KW
Air pressure:	0.5-0.8MPa
Blade specification:	Φ500xΦ30x4.4 Z=120 (standard size)
Cutter moving speed:	0-2m/min
Cutting length:	Max5000mm Min480 at 90° Max5000mm Min(double height of profile) at 45°
Cutting width:	120mm
Cutting height:	230mm
Cutting angle:	45°-157.5°
Repeat locating length error:	±0.2mm
Surface plainness:	±4´
Overall dimension:	6800mmX1500mmX2040mm
