XZS-350 Whirlpool Vibration Screener
I. Applications:
XZS-350 Whirlpool Vibration Screener is suited to continuous working mode production, are the ideal equipment for continuous discharging of material of different size ratio after going through sieves.
The machine consists of hopper, vibration chamber and coupling and motor. There are eccentric wheel, rubber of parts, main shaft bearing and so on. The adjustable eccentric weight can drive to the central line of main shaft through motor under the unstable state; it produces centrifugal force that makes raw material from vortex in the sieve. The size of amplitude of eccentric weight can be regulated in accordance with the different raw materials.
The machine is compact in structure, small in size, free of dust and makes little noise. It is highly efficient and low energy consuming, easy of moving and ease of maintenance.
2. Main Techinical Specification:
| Modle | XZS350 |
XZS515 |
XZS650 |
| Productivity kg/h | 60-500 |
60-1350 |
180-2000 |
| ScreenMeches | 12-200 |
12-200 |
12-200 |
| Screen Diameter mm | φ350 |
φ515 |
φ650 |
| Power kw | 0.55 |
0.75 |
1.5 |
| rpm | 1380 |
1450 |
1370 |
| Overall Dimensions mm | φ540×1060 |
φ710×1290 |
φ880×1350 |
| Net weight kg | 100 |
180 |
250 |
Each model is provided with double,or triple outlets | |||
Adjustment of vibratiy rang 1-6 mm | |||
3.Sample Photos
