Help CenterBest Quality PE Stretch Film Machine
Related Products
-
Best Quality Stretch Film Wrapping MachineUS$ 9,000 - 50,000MOQ: 1 Set -
High Speed Stretch Film Rewinding MachineUS$ 5,000 - 20,000MOQ: 1 Set
-
Best Quality Double-layer Co-extrusion Stretch Film MachineUS$ 15,000 - 50,000MOQ: 1 Set
-
Co-extrusion Stretch Cling Film / Wrapping Film MachineUS$ 15,000 - 50,000MOQ: 1 Set
-
Waste Edge of Stretch Film CrusherUS$ 1,500 - 2,000MOQ: 1 Set
Specifications
uses LDPE / LLDPE as main materialmake single / double-side self-sticky stretch film (wrapping film, fresh-keeping film)
Summary:
This PE stretch film machine uses LDPE / LLDPE as main material and adopts several kinds of resins to manufacture the single / double-side self-sticky stretch film (wrapping film, fresh-keeping film). The film has good tensile strength, anti-pricking ability and impact strength. Its good shrinking memory function and self-sticky can make goods integrity to prevent goods from loosening and collapsing during transportation and being polluted by dust. The transparency and tensile strength of this product can make the packaging beautiful, economical and practical. The film can be widely used in wrapping of palletized goods. It’s a good substitute for hot shrinking packaging film during transportation.
Extra optional equipments:
1) Auto Loader
2) Auto Screen Changer
3) Dry Hopper
4) Air Shaft
5) Auto Winder Changer
6) Glue Pump
Main Technical Parameters:
Model |
TR-SSF55-750 |
TR-SSF65-1250 |
Film Folding Width |
300-600mm |
600-800mm |
Film Thickness |
0.008-0.03mm |
0.008-0.05mm |
Screw Diameter |
Φ55 |
Φ65 |
Screw L/D Ratio |
28:1 |
|
Screw Rotating Speed |
10-120rpm |
|
Screw & Barrel Material |
38CrMoAl |
|
Die Width |
750mm |
1250mm |
Film Width |
600mm / 300mm×2 |
1000mm / 500mm×2 |
Film Thickness |
0.015-0.05mm |
|
Film Winding Diameter |
Φ200mm |
|
Main Motor Power |
11kw |
15kw |
Heating Power |
15kw |
25kw |
Output |
30kg/hr |
50kg/hr |
Machine Weight |
3000kg |
4000kg |
Overall Dimension |
6000×1500×2500mm |
6000×2000×2500mm |
