Specifications
slite and rewind PE stretch film, wrapping film, cling filmPLC+touch screen
multifunctional slitting and rewinding machine
Summary:
It is a kind of multi-functional stretch film slitting and rewinding machine. It mainly slits large-sized or big roller stretch film into small ones, which avoids the split-level film and improves the technical index of product, such as level and appearance quality etc.
It mainly is used to re-wind the PE stretch film and PE cling film. The automatic rewinder can greatly improve the work efficiency.
Features:
1- It is the latest style of stretch film rewinder machine in China.
2- Adopt PLC + touch screen. Guarantee the operation easier and more correction.
3- The speed is controlled by AC motor + Inverter control system.
4- The conveyer belt is the strong Teflon brand which import from Germany.
Main Technical Parameters:
Model |
TRRW-500 |
TRRW-1000 |
Width of Finished Products |
500mm |
1000mm |
Motor Power |
1.5kw |
3kw |
Linear Speed of Machine |
400m/min |
300m/min |
Roll Laying Mode |
By hand |
|
Max. Diameter of Mother Roll |
Φ400mm |
|
Max. Width of Mother Roll |
500mm |
1000mm |
Core Diameter of Mother Roll |
3” |
|
Width of Sub-roll |
500mm |
1000mm |
Max. Diameter of Sub-roll |
Φ300mm |
|
Core Diameter of Sub-roll |
3”, 2”, 1” |
|
Machine Weight |
700kg |
1200kg |
Overall Dimension |
1400×1100×1100mm |
1900×1100×1100mm |
