Super High Precision Mobile Phone Bga Rework Station With Optical Aligment Fix 01005 Capacitor
US$ 1 - 49,999
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
Shuttle Star
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/Hong Kong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Moblie Phone BGA Rework Station SP360CUS$ 1 - 999MOQ: 1 Set -
Automatic BGA Rework Vacuum Soldering Desoldering Station for Mobile Phone RepairingNegotiableMOQ: 1 Set
-
Manufacture to Customer! Full Automatic Bga Rework Station SV650A Repair GPU CPU ChipsetNegotiableMOQ: 1 Set
-
Hot Air BGA Rework Station SV650 Vacuum Desoldering Station for CPU GPU RepairNegotiableMOQ: 1 Set
-
Hot Air BGA Rework Station Chip Soldering Machine PS400 With Split Vision AlignmentNegotiableMOQ: 1 Set
Condition
New
Place of Origin
Guangdong, China
Brand Name
Shuttle Star
Model Number
Micra-20
Dimensions
L600*W800*H900
Weight
140Kg
Usage
PCB Soldering, Fix tiny components on mobile phone
Certification
CE ISO
After-sales Service Provided
Overseas third-party support available
Shuttle star Micra-20 was designed to rework tiny components such as 01005, 0201 resistor&capacitor.
Features
- 0.5mm diameter suction nozzle , can absorb smaller BGA
- 5 mega-pixel color optical system with functions of split vision, zoom-in and micro –adjustment, equipped with telecentric lens cone
- Top heater use the patent cooling , heating integration device ;powerful whirlwind function make the temperature more uniform.
- High-precision alignment system combin PC+Servo +CCD, friendly program interface
- Cross roller guide way+precision control wheel, achieve the micron grade adjust on the working working platform
- Nozzle pressure control more precise
- Automatic indentification the mounted height
- Precise vacuum control system ,can absorb the smaller chip
- Suction nozzle can rise, autorotation, alignment, soldering and desoldering
- Convenient operate button, can continue finish the related process action after press button
- More precise temperature control under closed cycle temperature control way
- Two independent temperature zones,(top hot air heating ,under hot air heating),temperature and time can be displayed digitally on the touch screen,able to rework CGA
- Bottom heater are 3 IR heating tube from Germany ,equipped with high temperature glass cover can stable the temperature,control heating independent
- Can adjust the preheating area according to the PCB size, Help the whole PCB constant temperature ,avoid distortion; abnormal overtemperature protection function ,friendly to the environment
- Laser alignment ,easy for PCB place
- Can save mass temperature file
- Finished the BGA rework process under the nitrogen protection, have special function for save nitrogen to save cost
-
Durable alloy steel nozzle, able to rotate in 360°
Specification PS400
| Item | Qty. |
| Applicable PCB Size | W30×D30~W150×D200mm |
| Min. component | 0.4×0.2mm |
| Placement precision | 10um |
| Top Heater | 1000W, 350°C |
| Bottom Heater | 2500W, 350°C |
| Control Mode | 8 segment programmable temperature setting |
| Power Supply | Single-phase 220V, 50/60Hz |
| Machine Dimension | L600×W800×H900mm |
| Weight | 140Kg |
Packaging & Shipping
Packaging: Standard Plywood Case with Machine carefully fixed inside
Delivery: Delievery about 3~4 weeks after get payment
Our Services
- 1 year warranty
- We offer free training on operating personnel and service within the warranty
- We free lifelong training for maintenance, if any question, assistant videos are also provided in after-sale service
- Under warranty, we send spare parts to the customer and afford all the cost and freight if any spare part is broken
Company Information
Shenzhen Shuttle Star Technology Co., Ltd. is one of the earliest professional BGA rework station manufacturers in China. Ever since founded in 2000, the product structure and performance are improved constantly according to the market demand and the product series has covered the from high-end to low-end and can provide complete solutions for the BGA reparation operation according to the special demand of customer.
