Hot Air BGA Rework Station Chip Soldering Machine PS400 With Split Vision Alignment
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
Shuttle Star
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/Hong Kong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
X-ray Machine Testing IC Bonding, BGA, SolderingNegotiableMOQ: 1 Set -
Super High Precision BGA Rework Station Can Fix Size 01005 Resistor & CapacitorUS$ 1 - 49,999MOQ: 1 Set
-
New Product! Shuttle Star SV650A Automatic Bga Rework Station With Optical Alignment Repair All Kinds of MotherboardNegotiableMOQ: 1 Set
-
Manufacture to Customer! Shuttle Star PS400 Automatic Bga Rework Station With Optical Alignment Repair Mobile PhoneNegotiableMOQ: 1 Set
-
Super High Precision Mobile Phone Bga Rework Station With Optical Aligment Fix 01005 CapacitorUS$ 1 - 49,999MOQ: 1 Set
Condition
New
Place of Origin
Guangdong, China
Brand Name
Shuttle Star
Model Number
PS400
Dimensions
600*600*750
Weight
80Kg
Usage
PCB Soldering, Reballing machine BGA rework station
Certification
CE ISO
Hot air BGA rework station chip soldering machine PS400 with split vision alignment. BGA rework station, BGA replacement, BGA repair, SMT, SMD, reballing, reflow, soldering machine, desolder, laptop, Xbox, infrared, LED, automatic, pick and place, optical alignment, hot air, IR, welding
Features
- The design is gorgeous and room-saving;
- Hot air head and mounting head are designed 2 in 1, and have both the auto soldering and mounting function;
- Powerful cross flow fans cool the bottom heating zone rapidly and constantly;
- Color optical system with functions of spilt vision, zoom-in and micro-adjust, equipped with aberration detection device; with auto focus and software operation function, 27X optical focus;
- Embedded industrial computer, PLC control, real-time temperature profile display, can display set profiles and 5 practically-tested profiles; able to analyze the 5 practical, and compare with the history saved profiles.
- Built-in vacuum pump;60 rotating in φ angle mounting nozzle is micro-adjustable;
- 8 segments of temperature up (down) and 8 segments of constant temperature control, no limited profile curves can be stored in the industrial compute;
- Suction nozzle can identify material and mounting height automatically, and can control the air pressure within a small range;
- Equipped with different hot air nozzles, easy to replace and able to locate in any angle;
- Big size splint, equipped with deformation-proof supporting device,suitable for the accurate rework of all kinds of PCB.
Specification PS400
| Item | Qty. |
| Applicable PCB Size | W20×D20~W350×D350mm |
| Applicable BGA Size | 1*1~70*70mm |
| Max. BGA weight | 80g |
| Alignment Micro-adjust | ±10mm forward/backward, ±10mm left/right, 60° rotation |
| Top Heater | 350°c |
| Bottom IR Heater | 400°c |
| Lower Heater | 350°c |
| Placement Precision | 0.01mm |
| Temperature Control | 16 sections of programmable temperature control |
| Power | Single-phase 220V, 50/60Hz |
| Machine Size | L600×W600×H750 |
| Machine Weight | Appox. 60Kg |
Packaging & Shipping
Packaging: Standard Plywood Case with Machine fixed inside
Delivery: Delievery within 1 week after get payment
Standard Accessories
| Item | Qty. |
| BGA Reball Kit(BK98D) | ×1set |
| Stencil/Mask | ×33pcs |
| Solder Paste/Flux | ×1tin |
| Leaded Solder Ball(0.45, 0.5, 0.6mm) | ×1tins |
| Upper Nozzle(five for upper, two for bottom) | ×7pcs |
| PCB Clamp for Laptop Motherboard | ×1set |
| Temperature Measurement Wire | ×1pc |
| High Temperature Cloth | ×1pc |
| Hex Key Wrench-set | ×1pc |
| Aluminum Plate | ×1pc |
Our Services
- 1 year warranty
- We offer free training on operating personnel and service within the warranty
- We free lifelong training for maintenance, if any question, assistant videos are also provided in after-sale service
- Under warranty, we send spare parts to the customer and afford all the cost and freight if any spare part is broken
Company Information
Shenzhen Shuttle Star Technology Co., Ltd. is one of the earliest professional BGA rework station manufacturers in China. Ever since founded in 2000, the product structure and performance are improved constantly according to the market demand and the product series has covered the from high-end to low-end and can provide complete solutions for the BGA reparation operation according to the special demand of customer.
