Tubular turbine electrical generator mini hydro power plants
The tubular turbine is applicable for the hydropower station with strong and low hydraulic head, the applicable hydraulic head is commonly from 4 to 25m.It has been widely used at plains and the tidal power generation of coastal areas.
The advantages of mini tubular turbine electrical generator horizontal type
The structure is simple,maintenance is easy. because of the horizontal-axis type and simple flow channel design, compared with the same scale turbine, there are many advantages.
1) The building projects of tubular turbine is less about 20%
2) The efficiency is more than about 30%
3) The electrical equipment budget saving about 15%.
4) Because the construction is convenient, construction period is short.
The parameter of tubular turbine electrical generator for your reference
| Output power (KW) | Rated head (m) | Rated flow (cbm/s) | Rotor speed (RPM) | Pipe diameter (mm) |
| 35 | 5 | 0.91 | 750 | 500 |
| 40 | 5.5 | 0.95 | 750 | 500~600 |
| 45 | 6 | 0.99 | 750 | 500~600 |
| 55 | 6.5 | 1.03 | 750 | 500~600 |
| 60 | 7 | 1.07 | 1000 | 500~600 |
| 65 | 7.5 | 1.11 | 1000 | 500~600 |
| 75 | 8 | 1.15 | 1000 | 500~600 |
| 80 | 8.5 | 1.18 | 1000 | 500~600 |
| 85 | 9 | 1.22 | 1000 | 500~600 |
| 95 | 9.5 | 1.25 | 1000 | 500~600 |
| 100 | 10 | 1.28 | 1000 | 500~600 |
