Modular Designed Asphalt Mixing Plant
with CCC/ISO9001 Certificate on Sale
1.precisely
2.can make automatic
3.semi_automatic
4. manual control with stable,reliable performan
5.exported most
1. The original modular design of the mixing plant makes transport and installation work quick and convenient. It can separate extra-large flotsam from usable stuff.
2. The loop belt feeder for the measuring hopper has a frequency-conversion speed regulator which can provide high and low speed. Its original structure facilitates belt change and makes material feeding more fluent, which reduces power consumption. Besides, there is a warning light which will remind the user when the machine uses up raw material.
3. The high-efficiency and heat-preservation drying drum and the special vanes make heat exchange more sufficient. Moreover, the high-efficiency and energy-saving imported burner can use both heavy oil and diesel, which reduces energy consumption.
4. The vibrating screen adopts the linear and completely-closed design with the vibrator placed outside. The sieving efficiency is high, the maintenance and changing of screen is easy, and the imported bearings are more reliable.
5. The hot aggregate bin is equipped with a continuous level indicator which enables the operator to know the level of material at a glance.
6. The main mixing machine designed with European technology has double reducers with a high-speed synchronization capacity. Accurately-weighed asphalt can be directly pumped into the agitating kettle and powder material can be conveyed into the agitating kettle through the helix, which makes agitating more even and speedy.
7. The dust-removing system adopts imported NOMEX bags which limit the density of dust discharged into the air within 50mg/m³, which is completely up to the national standard of environmental protection. The dust blown down will be collected into the collection tank through the dust lifter for reuse to avoid secondary pollution.
technical parameters of LB series asphalt aggregate mixing equipment
Type |
LB500 |
LB750 |
LB1000 |
LB1500 |
LB2000 |
LB2500 |
LB3000 |
LB4000 |
|
Rated production |
40t/h |
60t/h |
80t/h |
120t/h |
160 t/h |
200 t/h |
240 t/h |
320 t/h |
|
Dry cylinder |
1.1m×4.2m |
1.3m×5m |
1.5m×6m |
1.8m×7m |
2.2m×8m |
2.35m×9m |
2.5m×10m |
2.8m×11m |
|
Bag dust-remover |
CNM156 |
CNM240 |
CNM357 |
CNM476 |
CNM654 |
CNM832 |
CNM1012 |
CNM1308 |
|
Emission standard |
50mg/nm3 |
50mg/nm3 |
50mg/nm3 |
50mg/nm3 |
50mg/nm3 |
50mg/nm3 |
50mg/nm3 |
50mg/nm3 |
|
Vibrating screen |
4 layers |
4 layers |
4 layers |
4 layers |
5 layers |
5 layers |
5 layers |
5 layers |
|
Mixing kettle capacity |
500kg |
750kg |
1000kg |
1500kg |
2000kg |
2500kg |
3000kg |
4000kg |
|
Mineral powder tank volume |
30t |
30t |
26+36t |
26+36t |
30+43t |
30+43t |
50+35t |
60+35t |
|
Asphalt tank volume |
30000L |
30000L |
50000L |
50000L |
2×50000L |
2×50000L |
3×50000L |
4×50000L |
|
End-product container volume |
50t |
50t |
90t |
90t |
110t |
110t |
200t |
200t |
|
Weighing accuracy |
Aggregate |
≤±0.4% |
≤±0.4% |
≤±0.4% |
≤±0.4% |
≤±0.4% |
≤±0.4% |
≤±0.4% |
≤±0.4% |
Powder material |
≤±0.3% |
≤±0.3% |
≤±0.3% |
≤±0.3% |
≤±0.3% |
≤±0.3% |
≤±0.3% |
≤±0.3% |
|
|
Asphalt
|
≤±0.2% |
≤±0.2% |
≤±0.2% |
≤±0.2% |
≤±0.2% |
≤±0.2% |
≤±0.2% |
≤±0.2% |
|
