Help Center(HW258) Plastic Bottle Injection Machine Plastic
Related Products
-
(HW106) Plastic Injection Molding MachineryUS$ 17,000 - 17,000MOQ: 1 Set -
(HW106) PPR Injection Moulding MachineUS$ 13,600 - 16,600MOQ: 1 Set
-
(HW148) Servo Motor Injection Molding Machine PriceUS$ 15,200 - 20,500MOQ: 1 Set
-
HANVOS160 Injection Plastic MachineUS$ 16,000 - 18,000MOQ: 1 Set
-
3000g Plastiv Injection Molding Machine HW658US$ 16,000 - 16,800MOQ: 1 Set
Specifications
Plastic bottle injection machine plasticHANVOS energy-conserving king's series
Durable
Stable performance
Environmental
plastic bottle injection machine plastic
"HANVOS" energy-conserving king's series machines have been succeed in manufacturing.The machine which succeed in developing indicate that "HANVOS" enters into the energy-conserving advanced field of the injection molding machine HWJ "energy-conserving king",Which not only inproved the internsity of rigidity of the mechanical part,ut also converient to install and dismantle.Also the appearance of HWJ machine adopts the arcdesign,which can reflecting humanization design of "people fist",keen notion making progress idea "HW" HWL series energy-conservation machines use global advanced energy-conserving science and technology,the new-type energy-conservation injection molding machines of the research,design and manufacture all by oneself.It can reduce the cost of customers greatly!HWL series is the idea machine to all clients. Please see the picture and explanatory note in detaited the HWL series machine as following
MOLD LOCKING UNIT
l The burring , double-toogle three-link-rod five-hinged has the features of smooth motion ,large moving die stroke .
l Fine rididty, four-stage mode lock pressure, speed, defferential quick mode lock device have multiple means of ejection functions.
l Automatic centralized lubrication system.
l Gear regulating the mould driven by oil motor.
l Electrical &mechanical safety protection device.
INJECTION UNIT
l Dual-cylinder parallel injection;
l Low speed high torque oil motor directly drives screws to complete the pre-injection, with anti-dripping device.
Multiple-stage control for pressure, speed, position to inject, keep pressure, charge material
CONTROL UNIT
l It utilizes the plastic jetting-moulding machine special-purpose computer ,CPU work division control treatment ,the ejection.
l Clamp ,injection actions can choose linear displacement sensor for its control .
l It also real-timely monitors various actions and gives automatic warning for its defects.
l Multiple-unit plastic moulding data memory system.
HYDRAULIC UNIT
l It employs the imported hudrautic elements and components,uses the propotional pressure, propotional flow means ,offers live load dynamic force.
l Double injecting move jar vertical balance on both side of injection tube ,insured that spray nozzle can not be skew .
l The sealing is good and do not leak the glue.
l Low noise & rapid response oil pump system
l Adopt the cooling water flow distributor,controlling the cooling temperature easily.
Main technical parameters
Specification |
Unit |
HW258 |
|||
A |
B |
C |
|||
Injection unit |
Screw Diameter |
mm |
50 |
55 |
60 |
Screw L/D Ratio |
L/D |
23 |
21 |
19.2 |
|
Shot Size(Theoretical) |
cm3 |
530 |
641 |
763 |
|
Injection Weight |
g |
482 |
583 |
694 |
|
Injection Pressure |
Mpa |
223 |
184 |
155 |
|
Screw Speed |
Rpm |
230 |
|||
Clamping unit |
Clamp tonnage |
KN |
2580 |
||
Toggle stroke |
mm |
550 |
|||
Space Between Tie Bars |
mm |
560*560 |
|||
Max Mold Height |
mm |
580 |
|||
Min Mold Height |
mm |
220 |
|||
Ejector Stroke |
mm |
140 |
|||
Ejector Number |
PC |
9 |
|||
Ejector tonnage |
KN |
71 |
|||
others |
|
|
|
||
Max Pump Pressure |
Mpa |
16 |
|||
Pump motor Power |
KW |
22 |
|||
Heater Power |
KW |
14 |
|||
Machine Dimension(L*W*H) |
mm |
5.7×1.5×2.1 |
|||
Machine Weight |
T |
7.1 |
|||
|
Fuel tank capacity |
L |
400 |
||
