Home > Manufacturing & Processing Machinery > Plastic Machinery > Injection Molding Machine > (HW106) Plastic Injection Molding Machinery

(HW106) Plastic Injection Molding Machinery

Name: (HW106) Plastic Injection Molding Machinery
Brand: HANVOS
SKU: 125699919

(HW106) Plastic Injection Molding Machinery thumbnail-1

(HW106) Plastic Injection Molding Machinery photo-1

US$ 17,000 - 17,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Type:

Preform Injection

Style:

Horizontal

Contact Supplier Request Quote Chat Now

Shanghai Panxun Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Type Preform Injection

Style Horizontal

Brand Name HANVOS

Model Number HW106

Place of Origin Zhejiang, China

Plastic Type Thermoplastic

Automatic Yes

Injection Weight 113/127/149g

Injection Rate 79/89/105cm3/s

Clamping Force 1060KN

Opening Stroke 320mm

Certification CE

After-sales Service Provided Overseas service center available

Plastic Injection Molding Machine

HWS series machines having advantages of other HW series machines are loading with high performance servo motor. Its delivered power vaies with loading power without any excess energy waste. During pressure maintenaning period, servo motor consumes little energy for lowering speed of motor while no work in cooling time. Compared with average injection machnes, servo motor machines can have 20%~80%electricity-saving.

Please see the picture and explanatory note in detailed the HW series machine as following.

		CLAMPING - FEA designed double-toogle five-joint clamping machinery - High rigidity mould platen with enlarged space between tie bar, fit for larger scope of the moulds - Mould platen with both T-slot and mould mounting holes - Large moving die stroke with smooth & fast motion - Electrical & mechanical safety protection device - Four-stage control for pressure, speed, position to lock & open the platen - Automatic centralized lubrication system - Differential quick mode lock device - Gear regulating the mould driven by oil motor

		INJECTION UNIT - Twin cylinder balanced injection system - High torque oil motor directly drives screw to complete the pre-injection - Specific screw and barrel designs are available for processing different material requirements to ensure the production quality - Multiple-stage control for pressure, speed, position to inject, keep pressure, charge material

		CONTROL UNIT - It utilizes the plastic injection moulding machine special- - purpose computer with rapid response, interactive interface - Regulate barrel temperature deviation automatically - Multiple-unit plastic moulding data memory system safety performance of electric devices - It real-timely monitors various actions and gives automatic warning for its defects - Clamp, injection, ejection action can choose linear Displacement sensor for its control

		HYDRAULIC UNIT - High capacity feedback proportional valve controlling the pressure and flow, stability and high sensitivity speed - Main hydraulic components with world famous brand, ensuring stable quality of the machine - Low noise & rapid response oil pump system - Adopt the cooling water flow distributor, controlling the cooling temperature easily
