Specifications
1)Chlorine Peroxide Generator (Clo2 Generator)2)Low energy consumption
3)High efficiency
4)Good disinfection effect
Chlorine Dioxide Generator
1. Composition:
It consists of feeding system, reaction system, control system, mixing and absorption system, security system.
2. Reaction Principle:
NaCLO3+2HCL→CLO2+1/2CL2+NaCL+H2O
Raw material:sodium chlorate(GB/T1618-1995, content: more than 99%),
hydrochloric acid(GB320-93, concentration : more than 31%).
3. Features:
(1) For production of compound disinfectant (chlorine dioxide as main, chlorine gas as auxiliary), calculated by available chlorine, CLO2 : more than 75%.
(2) Flow-meter dosage system for transferring raw material ensures simple operation, accurate material input, un-blockage and stable performance.
(3) Main reaction pot adopts imported compound material that is temperature-resistant, anti-corrosion with long life time.
(4) Total convertible rate of raw material≥85%,low energy consumption.
(5) Semi-auto run of machine, no need of extra worker if there’s enough material.
(6) Upper-positioned material basket is suitable for low water pressure area.
4. Consumption of raw material:
1g available chlorine consumes 0.65g sodium chlorate and 1.3g hydrochloric acid
5. Technical Parameters:
Model |
Available chlorine output(g/h) |
Pressure(Mpa) |
DN1(mm) |
DN(mm) |
Power(Kw) |
BT-50 |
50 |
≥0.20 |
25 |
32 |
0.5 |
BT-100 |
100 |
≥0.20 |
25 |
32 |
0.5 |
BT-200 |
200 |
≥0.20 |
25 |
32 |
0.5 |
BT-300 |
300 |
≥0.20 |
25 |
32 |
0.5 |
BT-500 |
500 |
≥0.20 |
25 |
32 |
0.5 |
BT-800 |
800 |
≥0.20 |
25 |
32 |
0.5 |
BT-1000 |
1000 |
≥0.20 |
32 |
40 |
0.5 |
Shandong Better Enviromental Protection Technology Co.,ltd,
is the biggest environmental protection water and waste treatment machinery company in Shandong Province,
it's a high-tech enterprise, adopted the US technology,
with experience over 10 years, during the past decade,
we won very good reputation among our customers all over the world,
Turkey, Janpan, Australia,Bangledesh, Saudi Arabia, Iran, etc.
We'vre got the national patent for our below products:
Solution Advice, Installation &. Operation Guide.
You can provide us the water sources, water quality, flow rate and ground area, material requirements about your project, then more technical solutions will be suggested to you.
