Cold room(double temperature)
Feature:
size: 6000mm(L)*2300mm(W)*2438mm(H)
temperature:+10degree C/-20degree C
steel sheet: painted galvanized steel
*Panel: both sides 0.326mm painted galvanized steel polyurethane panel thickness 100mm
*Door:both sides 0.326mm painted galvanized steel polyurethane hinge door thickness 100mm,size 832mm W*1860mm H
*one set of pressure relief vent
*fission type refrigeration unit,with evaporator,expansion valve,control box etc.--with CE certificate
*light and switch included
Product information
| Dimension | Length (m) *Width (m)*Height (m) |
| Panel | polyurethane insulation panel,43kg/m3, fire retardant |
| Foaming material | BASF environmental friendly |
| Panel thickness | 50mm,75mm,100mm,150mm,200mm |
| Steel cover | painted galvanized steel(optional:stuccom embossed aluminum,,stainless steel,PVC stell) |
| Panel connection | cam lock type, use hexagonal key to assemble and disassemble |
| Type of door | hinged door(sliding door&convex door optional) |
| Temp.of room | -20 degree C |
| Purpose of cold room | fruit,vegetable,flower,fresh/frozen meat etc |
| Refrigeration unit | Copeland |
| Refrigeration type | air cooled |
| Fittings | all necessary fittings are included, optional |
| Place to assemble | indoor/out door(concrete construction building/steel construction building) |
| Voltage | 220V/50HZ, 220V/60HZ, 380V/50HZ optional |
Our cold room panels meets JB/6527-2006<modular cold room insulation sandwiched panel’s technology conditions> standard request.
Through measuring and testing, our panels are in line with GB8624-2006 <Fflammability of building materials classification method, reach Class B1 flame retardant materials requirements.
Cold storage panel without retardant is flammable. Our panels with fire retardant can increase security of cold room , big cold room with retardant is requested according to nation regulations.
The foaming material we choose is imported BASF foaming material, green to the environment.
The steel sheet we purchase from Baosteel and POSCO which are the biggest steel factories in the world, they promise the painted galvanized steel they produce will not fade in 15 years.
All the panels are with gasket at the joint of two panels, enable the cold room with better air-tightness, but not many panel factories realize this point or just ignore this to save the cost.
Cold room door
Hinged door
Refrigeration unit
Loading:
We use bubble paper and plywood etc package to protect all the panels and fittings in a sturdy condition. To avoid damage in the transportation.
