Abs Injection Molding Machine

Abs Injection Molding Machine thumbnail-1
Abs Injection Molding Machine photo-1
US$ 8,000 - 8,200 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, screw injection
Style:
Vertical
Contact Supplier Request Quote Chat Now
Dongguan Zan Yi Machinery Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other, screw injection
Style Vertical
Brand Name ZAN YI
Model Number ZY-250ST
Place of Origin Guangdong, China
Plastic Type Thermoplastic
Automatic Yes
Injection Weight 56g,64g,74g
Injection Rate 57cm3/sec,66cm3/sec,75.5cm3/sec
Clamping Force 35T
Opening Stroke 180mm
Power(W) 6.3KW
Certification CE,ISO9001:2008
After-sales Service Provided Engineers available to service machinery overseas

abs injection molding machine

Product Details:

Item Name: desktop injection molding machine



Specifications:
MODEL UNIT ZY-250ST
Screw Diameter Mm 26 28 30
Injection Pressure kg/cm² 1530 1278 886
Theoretical Shot Volume cm³ 61 70.8 81
Max.Shot Weight(ps) g 56 64 74
Safe Shot Weight(ps) OZ 2 2.27 2.6
Max.Shot Weight(ps) cm³/sec 57 66 75.5
Injection Rate mm 115
Screw Speed Max. rpm 0-205
Nozzle Comtact Force Tons 4.45
Nozzle Retraction Stroke mm 170
Number of Temperature Control   3
Clamping Force Tons 35
Platen Size mm 540*380
Distance between tie bere mm 375*205
Min.Mold Height mm 158/58
Opening Stroke mm 180
Max.Open Daylight mm 338/238
Ejetor Force Tons 1.3
Ejetor Stoke mm 35
Max.Hydaulic Pressure kg/cm² 140
Pump Output l/min 34.5
Oil Resservoir Capacity l 100
Cooling Waer Consumption l/hr 400-600
Pump Motor Power KW/HP 3.75/5.5HP
Berrel Heating Power KW 2.4
Total Electricity KW 6.3
Packing Weight Kg 1150kg
Packing size(LxWxH) m 1.45*1.15*2.26



 Features:

1.Straight scew ejected assembly.

2.Two(three) phase temperature ,ejected speed,backing pressure and screw speed is suitable for various plastic to confectioned.

3.Low-die fixed top active mode makes inserted objects excellent positioned features and the machine has liftout attachment for finished goods.

4.Low-pressure closed die assembly can protect the safety of die .

5.Material tube can be lifted ,It is easy to clean stub bar .It is easy to fix die .

6.Can be installed a single mold or double shuttle table.

Samples produced:

abs injection molding machine
