Specifications
High BrightnessHigh Resolution
High Density Electronic Full Color Display
Low Power Consumption
Wide Viewing Angle
1)With good lightening accordance and no mosaic.
2)Can play different formats of image files, flash, video signal from TV, video and other equipments.
3)Different video frequency can be changed freely at the same time, and the image can be enlarged and shrinked.
4)High brightness, and can be adjustable, meets the needs of customer's requirements.
5)Uses real pixels rather than virtual pixcels, better viewing effect .
Indoor SMD Fixed Installed Commercial LED Displays | |||||
Module | Pitch/mm | P3 | P4 | P5 | P6 |
Module size/mm | 192x96 | 128x128 | 160x160 | 192x96 | |
Density of pixel/(dots/m2) | 111111 | 62500 | 40,000 | 27,777 | |
Pixel composition | SMD 3 in 1 | SMD 3 in 1 | SMD 3 in 1 | SMD 3 in 1 | |
Led encapsulation | SMD2020 Black Lamps | SMD2020 Black Lamps | SMD3528 White Lamps | SMD3528 White Lamps | |
Resolution of module | 63x32 | 32X32 | 32X32 | 32X16 | |
Main | Optimum viewing distance | 3-10m | 4-15m | 6-16m | 7.5-20m |
View angle / ° | 140H,120V | 140H,120V | 140 H,120 V | 140 H,120 V | |
Max power consumption/W/M2 | 1200 | 1,000 | 1,000 | 900 | |
Size of cabinet/mm | 576x576 | 512X512 | 800X640 | 960X768 | |
Resolution of cabinet | 192x192 | 128X128 | 160X128 | 160x128 | |
Driving method | 1/16 scan constant current | 1/16 scan constant current | 1/8 scan constant current | 1/8 scan constant current | |
Refresh rate Hz/S | ≥600 | ≥600 | ≥600 | ≥600 | |
Luminance of white balance | ≥1500 nits | ≥1500 nits | ≥1500 nits | ≥1500 nits | |
Thickness | 110mm | ||||
Operation of Environmental Temperature/°C | below 30 to above 50 | ||||
Working voltage | 110-220 VAC/+/- 10% | ||||
Grey scale/color | displaying colors≥16.7M(synchronized) | ||||
Brightness adjustment | 4096 levels of each color(manually),100 levels of each color(automatically) | ||||
Input signal | RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc | ||||
Control system | linsn(sending card,receiving cards and Hubs) | ||||
Average of non-failure life | >50,00h | ||||
Life span | >100,000h | ||||
Functionless dot rate | <0.0001 | ||||
1)Reply your inquiry in 24 working hours.
2)Experienced staffs answer all your query in fluent English,Spanish,French,German etc
3)Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.
4)Special discount and protection of sales area provided to our distributor.
5)Warranty: Two Years, a little investment for longer warranty time.
