Product Details
Condition | New | Laser Type | CO2 | |
Applicable Material | Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, Wood | Cutting Thickness | 25mm thick acrylic laser cutting | |
Cutting Area | 1300*2500mm | Cutting Speed | 36000mm/s | |
CNC or Not | Yes | Cooling Mode | Water Cooling | |
Control Software | CorelDraw, AutoCAD | Graphic Format Supported | AI, PLT, DXF, BMP, DST, DWG, DXP | |
Place of Origin | Guangdong, China | Brand Name | Beyond Laser | |
Model Number | HS-B1530 | Certification | CE, ISO, UL, Other, CE, ISO, UL, EMC, FDA, BV | |
After-sales Service Provided | Overseas third-party support available |
Seaworthy wooden case.
Product Description
Specifications
High precision 3d laser crystal engraving machine HS-B1530600 High Temperature Annealing
High precision 3d laser crystal engraving machine
HS-B1530
Names | B series Acrylic Laser Cutting Bed models | ||
HS-B1325 | HS-B1525 | HS-B1530 | |
Work size(mm) | 1300×2500 | 1500×2500 | 1500×3000 |
Power | 135W | ||
Volume m3) | 13 | ||
Weight(kg) | 1000kg | ||
Exterior dimension(mm) | 3470*1892*1178 | ||
Wooden case dimension(mm) | 3570*1970*1178 | ||
Transmission model | Steel belt is fixed, the gear transmission | ||
The max free speed | 48m/min | ||
Reprecision | ±0.01mm | ||
Working power supply | AC220V±10% 50HZ | ||
PositionaI accuracy | 0.02mm | ||
Total power | ≤ 1800W | ||
Temperature | 0°C-40°C | ||
Humidity | 5-95% | ||
Formats | DXF,AI,PLT,CDR,BMP,PLT,DST | ||
Applied Materials | Apply to cut acrylic, LED light panels, MDF fiber board, composite board, advertising decoration materials, electrical panel such as cutting, designed for high precision cutting of the user |
1. If there is no special requirements,the ray intensity should be less than 80 percent,thus to avoid the tube aging quickly. |
2.Water temperature should be examined at all times during the working process.Once the water turns to warm,please change it fight away(the right way of changing water is to get out of some some hot water and fill in cold water. |
3.Water tank ,water pump and water inlet and out rubber tube should be cleaned once every four days. |
4. focal lens should be cleaned after removal.And the lens should be fixed firmly but not too tightly for fear of break after cleaning. |
5.The minimum amount of cooling water should not be less than 30L.Make sure that the water can submerge the submersible pump. |
6. Do not use circulating water of por quality ,because it may affect the laser power seriously and shorten the service life of laser tube .The manufacturer is not responsible for repairing the laser tube damaged by the using of poor-qualified water.It is suggested to use purified water or distilled water. |
