2.4ghz high power wireless cpe dual sim Ads promotion tool
1) Large-capacity hard disk local storage
2) Ads promotion tool
3) Support various business modes
4) Vehicle-mounted, compression resistance, anti-vibration design
5) Support maximum 200 people to visit the network on line
6) CPU: ARM dual-core/1.2GHz. Flash: 4G
7) Support GPS
8) Adopt 2.4GHz 2T2R 300Mbps technology and meet multi-user connection application
9) Provide Mini PCIE interface and SIM card slots, support user to expand built-in 3G/4G application
10) Support 2pcs 100Mbps LAN/WAN interface, meet different application
11) Provide TF card slot, suport 32G local storage, for expanding multi-media application
Terminal performance
1. Adopt high-performance ARM platform, it has the capability of accessing 100 people to watch video at the same time.
2. Powerful WIFI accessing capability, it can access 100 people and provide 1M speed for each person at the same time.
3. Expanded 3G/4G mode, support multiple module at the same time
4. Support GPS
5. Optimization design for vehicle application, aluminum case, no mechanical rotating parts, anti-vibration and water-proof design, fully meet bad weather and environment condition
6. Vehicle power design, can use under bad power supply condition
7. Support the use’s network speed limits
CPE P300 (FDD) | |
LTE Standard |
3GPP E-UTRA Release 9 |
Throughput |
100Mbps(DL) / 50Mbps(UL) @ CAT3 |
Point |
Just plug-in RJ45, then you can use LTE |
CPE P300 (TDD) | |
LTE Standard |
3GPP E-UTRA Release 9 |
Throughput |
68Mbps(DL) / 17Mbps(UL) @ CAT3 |
Point |
Just plug-in RJ45, then you can use LTE |
Hardware Specification (FDD) | |
Standard |
3GPP E-UTRA LTE Release 9, UE Category 3
|
|
Multiplexing
|
FDD
|
Supporting band |
UMTS/HSPA+ : 900M(BC8),2100M(BC1) LTE (FDD) : 1800M(B3) |
RF Paths |
1Tx, 2Rx |
Throughput |
DL/UL 100Mbps/50Mbps@ 20Mhz |
Activation |
USIM |
Max. Tx Power |
22dBm@ Antenna Port |
Hardware Specification (TDD) |
|
|
Standard
|
3GPP E-UTRA LTE Release 9, UE Category 3 |
Multiplexing |
TDD |
Supporting band |
LTE(TDD): 1900M(B39), 2300M(B40), 2500M(B38), 2600M(B41) TD-SCDMA : 2000M(BC34), 1900M(BC39) GSM 900/1800Mhz |
RF Paths |
1Tx, 2Rx
|
|
Throughput
|
DL/UL 68Mbps/17Mbps@20MHz
|
|
Activation
|
USIM
|
Max. Tx Powe |
22dBm@ Antenna Port
|
Functional Specification | |
|
Easy to use
|
Just plug in RJ45, then you can use LTE network |
|
LED indicator(3)
|
Power, 4G(4G/TDS/GPRS), LAN(RJ45), Power: 12V DC/1A
|
|
Interface
|
USIM, RJ45, Mini-USB, Reset, Main & Diversity LTE Antenna
|
|
Size
|
80*79*25mm
|
|
VPN
|
Support Customized VPN
|
|
Firewall
|
MAC / IP / Port Filtering, Port Forwarding, DMZ |
Function |
APN setting, Web-UI Based SMS , Telnet Server, Factory restore |
It can be used for public WIFI hotpot access, such as bus, bus station, bus stop, bus shelter, coach,train,train station, street lamp,city square, plaza, etc.
ODM services for CPE
1. Customize appearance, such as size, fixed mode.
2. Customize all kinds of data interface and ports, such as antenna, LAN, WAN, SIM/USIM etc.
3. Customize WIFI spec, such as connecting user number, cover distance, transmit power, transmit speed etc.
4. Provide technical support for customers.
5. Customize LOGO and packing.
6. Customize module needed.
7. Customize telecom standard needed.
After-sale service
