MGM Insulation Paper/ Mylar/Glass Fiber
- QINGDAO SHANGHAI
- D/P D/A Credit Card
You May Like
Product Details
| Place of Origin | China | Brand Name | HX | |
| Model Number | MGM | Type | Insulation Film | |
| Material | Composite Polymer |
Product Description
Specifications
Mylare Glass fiber cloth compositeF class, 155 degrees
Composite materials glass fiber cloth adhered to Mylar
MGM: Mylar+ Glass fiber cloth+ Mylar
MGM insulation paper
Mylar glass fiber cloth Mylar flexible composite foil
Features: Class F, 155 degrees Celsius.
High mechanical strength, excellent electrical property, and immerse the function.
Applications: As slot , interphase ,liner insulation for electric motors, generators, transformers or other electrical equipment.
Thickness: 0.17mm,0.20mm,0.25mm
INDEX | Unit | Desired value | |||
thickness | mm | 0.15±0.02 | 0.17±0.02 | 0.20±0.03 | 0.25±0.03 |
weight | g/m2 | 194 | 221 | 315 | 354 |
Tensile strength, the minimum:crosswise | N/cm | 140 | |||
100 | |||||
Elongation, minimum:crosswise | % | 3 | |||
2 | |||||
Breakdown voltage, the minimum | kv | 10 | |||
7 | |||||
