Insulation Armature Paper
- Qingdao&Shanghai
- T/T L/C D/P D/A
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | HX | |
| Model Number | 6630 DMD | Type | Insulation Paper | |
| Material | Composite Polymer | Application | Other, High Temperature, Motors, transformers, generators etc. | |
| Rated Voltage | 6-20kv | Tensile Strength | high |
Product Description
Specifications
1. Dacron/Mylar/Dacron (Polyester film/Pet fabric)2. B class, 130 armature paper
3. For motors, transformers, generators
6630 DMD B Class Flexible laminate, Dilectric Armature
B CLASS
130 Degrees Celsius
1. Composition/Process
Total three Layers: Dacron+Mylar+Dacron :( Two-layer polyester non-woven fiber fabric adhered to either side of one-layer Polyester film in
the center with high-melt-point B-class adhesive).
2. Features:
Super dielectric property.
Reliable heat resistance.
High mechanical strength.
Good impregnating performance.
3.Applications:
It is suitable for B-class electric motors, generators, transformers and
other electric appliances or equipment, insulation based on slot, interlayer,
liners and interturn.
4. Availabilities:
Thickness: 0.15-0.45mm.
Standard width: 1000mm.
Color: white blue,pink or customized as per customers' requirements
5. DM, DMDM can be customized. Didfferent layers are available.
6. Why not choose HAOXIANG ?
- Enviroment-friendly products
- High cost-efficiency
- A team of experienced professionals
- Customer- oriented approach
- Prompt response to customers' questions related to our products
