Ethiopia Mining Gold Shake Tables Separator

Ethiopia Mining Gold Shake Tables Separator thumbnail-1
Ethiopia Mining Gold Shake Tables Separator photo-1
US$ 900 - 3,200 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Gravity Separator
Production Capacity:
0.5-2t/h
Contact Supplier Request Quote Chat Now
Jiangxi Perry Mining Machinery Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Xiamen/Guangzhou/Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Gravity Separator
Production Capacity 0.5-2t/h
Place of Origin Jiangxi, China
Brand Name Perry 's Gold Shake Tables Separator
Model Number LS4500 Gold Shake Tables Separator
Voltage 220V-480V
Power(W) 1.1kw
Dimension(L*W*H) 5600*1850*860mm
Weight 750kg
Certification CE, ISO9001
Warranty 1 Year Excluding Spare Parts
After-sales Service Provided Engineers available to service machinery overseas
Product Description

Product Application of Gold Shake Tables Separator for Ethiopia Mining

The Gold Shaking Table is one of the main equipment of gravity concentration. It is not only widely applied on separating tungsten, the tin, the tantalum niobium and other rare metals and the noble metal ore.

Gold Shake Tables Separator

The Gold Shaking Table is also widely used in separation for Gold, Silver, Tin, Columbium, Tantalum, Titanium, Barium, Tungsten, Iron, Chrome, Manganese, Zircon, Lead, Zinc, Mercury, Copper, Aluminum, etc. The shaker effective recycling granularity scope s 2-0.22mm.

Specifications For Gold Shake Tables Separator
Model
LY(S)4500
LY3000
LY2100
LY1100
Deck size (mm)
4500×1850×1560
3000×1680×1380
2100×1050×850
1100×500×430
Concentration area (m2)
7.67
4.08
2
0.51
Feeding size (mm)
0.037-2
0.037-2
0.037-2
0.037-2
Feeding density (%)
10-30
10-30
10-30
10-30
Capacity (t/h)
1-2.5 (coarse)
0.6-1.5(coarse)
0.4-0.8
0.1-0.2
0.8-1.2 (fine ore)
0.3-0.8 (fine ore)
0.2-0.5(fine ore)
0.05-0.1(fine ore)
0.3-0.9 (slime)
0.2-0.6(slime)
0.1-0.4(slime)
0.03-0.05(slime)
Motor  power (kw)
1.1
1.1
1.1
0.55
Dimension (mm)
5630×1850×860
4075×1320×860
3040×1050×760
1530×500×660
Weight (kg)
750
650
400
100

Main Features Gold Shake Tables Separator

1) High separation accuracy. It can get final concentrates, middling, and tailing only for one time separation of the raw ore.

2) High concentration ratio. Gold Shake Tables Separator for Ethiopia Mining

3) High separation efficiency. Gold Shake Tables Separator for Ethiopia Mining

4) Easier safeguard  Gold Shake Tables Separator for Ethiopia Mining

5) The frequency stroke is easier to be adjusted. Gold Shake Tables Separator for Ethiopia Mining

Structure

Gold Shake Tables Separator

Gold Shake Tables Separator
Detailed Images

Deck

Gold Shake Tables Separator

There are 3 different deck designs available:
Gold Shake Tables Separator
(1) The coarse ore deck for 0.5 mm to 2 mm;

Gold Shake Tables Separator
(2) The fine sand deck for 0.074 mm to 0.5 mm;
Gold Shake Tables Separator
(3) The slime deck for 0.05 mm to 0.074 mm.

Head motion

Gold Shake Tables Separator for Ethiopia Mining
6-S Gold Shake Tables Separator is furnished with a totally enclosed self-oiling head motion of heavy cast iron to contain an oil reservoir for perfect splash lubrication. This feature protects the moving parts, reducing operating and maintenance costs to a minimum.

Support device

We mainly have 3 supporting device:
Gold Shake Tables Separator for Ethiopia Mining
#28 channel steel type support
Gold Shake Tables Separator
#10 channel steel type support
Gold Shake Tables Separator
#8 channel steel type support

Motor engine

Gold Shake Tables Separator for Ethiopia Mining
The motor engine for our shaking table is the type which is specially applied for export and which is with high quality.

Gold Shake Tables Separator for Ethiopia Mining

It is different from the one for domestic market.

Gold Shake Tables Separator

Siemens motors are available

Packing & Delivery

Pack after assemble

For single set, the shaking table is usually packed in steel frame after assemble.

Pack disassembled

For more quantity, the shaking tables are packed disassembled.

Full Container Loading

For FCL, the shaking tables are disassembled. The machines are loaded in the container, the spare parts are packed in wooden boxes.  Gold Shake Tables Separator for Ethiopia Mining

About Us
Jiangxi Perry Mining Machinery Manufacturing Co., Ltd is a company who specially supplies mining equipment for export, layout design, plant installation & debugging, and technical support. With more than 25 years' manufacturing experiences, our customers and services have covered more than 50 countries all over the world.

Main product: complete gold washing plant, Gold Shake Tables Separator, gold concentrator, jig, spiral chute, trommel screen, ore washing machine, crushers, grinding mills, screening equipment, and so on.
Our Service

Pre-Sales Service

Gold Shake Tables Separator

* Inquiry and consulting support.
Gold Shake Tables Separator
* Sample testing support.

Gold Shake Tables Separator

* View our Factory.
Gold Shake Tables Separator

After-Sales Service

Gold Shake Tables Separator

* Training how to instal the machine, training how to use the machine.
Gold Shake Tables Separator
* Engineers available to service machinery overseas.
