Product Specification
Item |
Specification |
Type |
Projected capacitive touch panel |
Model Number |
FN320A02-V1.0 |
Size |
32 inch |
Structure |
G+G |
Controller IC |
EETI 3188 |
Visible Area,mm |
698.70*393.30 |
Outline Dimension,mm |
781.54*476.14*3.30 |
Cover Glass Thickness,mm |
2.0 |
Interface |
USB/IIC/RS232 |
Touch Points |
10 touch |
Surface Hardness |
6H |
Transmittance |
> 87% |
Operating temperature |
-20℃~70℃ |
Storage temperature |
-30℃~80℃ |
Durability |
> 300 million touch |
Projected capacitive touch panel
Size:2.8”-32”standard CTPs available
Operating temperature range:-20~70℃
Storage temperature:-30~80℃
Remark: For more information please go to our website Http://
We can also make the matching module ( TFT + CTP ). Please contact us for details.
l. Cover lens customization
- Size:1.28”-42”
- Irregular shaped:support punching(down to radius 0.4mm)
- Color:different color silk printing or logo printing(UV resistance ink supportable)
- Strengthen glass:Coring Gorilla,AGC,Schott
- Thickness:0.55;0.7;1.0;1.1;1.8;2.0;2.5;3.0;4.0;5.0;6.0mm
2.Special function
- support true touch,max 10 points
- support different gloves(Nylon,Latex,Cotton,Wool,Snow gloves),max 5mm thickness
- Support passive stylus
- Support touch with water,oil,water-oil mixture,salt water
3.Sunlight readability
- hight brightness TFT 500nit~1600nit
- Optical boning technology
- AG/AR/AF coating
1. Standard capacitive touch panel (1.28 ~42 inch)and LCD touch screen in stock.
2. Complete customized solutions & special treatment.
3. Nearly 10 years experience in touch screen industry,we understand customer’s requests.
4. High quality and realiabity of our touch screen, and ensure long-term supply.
5. A strict quality control system.
6. High price-performance of touch screen.
7. Provide the best debugging and other after sales services worldwide.
Our Factory
Trade terms |
FOB CIF EXW CPT |
Payment terms |
T/T |
MOQ |
Normally 1k, but depends on different products |
Lead time |
4~8 weeks |
