China Heat Pipe Heat Exchanger Systems

China Heat Pipe Heat Exchanger Systems thumbnail-1
China Heat Pipe Heat Exchanger Systems thumbnail-2
China Heat Pipe Heat Exchanger Systems thumbnail-3
China Heat Pipe Heat Exchanger Systems photo-1
China Heat Pipe Heat Exchanger Systems photo-2
China Heat Pipe Heat Exchanger Systems photo-3
US$ 650 - 3,500 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
Quanbang
Contact Supplier Request Quote Chat Now
Wuxi Quanbang Energy Technology Co., Ltd.
Gold Verified Supplier
6Yrs
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Jiangsu, China
Brand Name Quanbang
Model Number RSCL
Structure Tube Heat Exchanger
Liquid Flow Rate customized
Weight customized
Dimension(L*W*H) customized
Certification Other, TUV
Warranty 1 year
After-sales Service Provided No overseas service provided

China heat pipe heat exchanger systems



This kind of heat transfer equipment are to recovers heat from waste heat source, such as waste water and waste gas in the factory. Mainly applied in chemical industry, cereals and oils industry, feed processing industry and so on.



Product Description

Type: Air –Air Heat Pipe Heat Exchanger

Function: recover the residual heat of exhaust gas

Operation temperature: 150℃~300℃

Distinguishing Feature:

1. high efficiency of heat recovery

2. startup under the small temperature difference and good isothermal condition

3. hard to bring the acid dew point corrosion

4. protecting he fresh air from pollution of waste gas

Material Feature:

carbon steel base tube with extruded aluminum fins



Fin Shape:



China heat pipe heat exchanger systems



Performance Parameter



Model

Air Flow(m3/h)

Windward

Tubes

Effective Length
(mm)

Heat Exchange

Area
(m2)

Total Heat Load
(kw)

L×W×H
(mm)




RSCL-13×25×0.9

7500

13

992

399

182

1212×2075×860



RSCL-14×25×1

10000

14

1029

533

242

1249×2075×1060



RSCL-14×25×1.1

11000

14

1132

586

267

1352×2075×1060



RSCL-14×25×1.2

12000

14

1235

639

291

1455×2075×1060



RSCL-15×25×1.2

15000

15

1263

799

363

1483×2075×1260



RSCL-16×25×1.3

18000

16

1389

959

436

1609×2075×1360



RSCL-18×25×1.4

20000

18

1425

1065

485

1645×2075×1460



RSCL-18×25×1.5

22000

18

1567

1172

533

1787×2075×1460



RSCL-19×25×1.6

25000

19

1653

1331

606

1873×2075×1560



RSCL-20×25×1.8

30000

20

1852

1598

727

2072×2075×1660





Application Field

Heat pipe heat exchanger with carbon steel tube and aluminum fins mainly applied in chemical industry, cereals and oils industry, feed processing industry and so on.





ISO Certificate



China heat pipe heat exchanger systems
