Air to air heat pipe heat recovery exchanger

Name: Air to air heat pipe heat recovery exchanger
Brand: Quanbang
Price: USD $12,000 - 18,000 / Unit

FOB Price

USD $12,000 - $18,000 / Unit

1 Unit(Min.Order)

Supply Ability 30 Unit / Units per Month
Port Shanghai
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Condition:	New	Place of Origin:	Jiangsu, China	Brand Name:	Quanbang
Model Number:	RSSS	Structure:	Tube Heat Exchanger	Liquid Flow Rate:	customized
Weight:	customized
Dimension(LWH):	customized	Certification:	Other, TUV
Warranty:	1 year	After-sales Service Provided:	No overseas service provided

Packaging Details

Customized Packaging

Product Description

Air to air heat pipe heat recovery exchanger

Heat transfer equipment are to recovers heat from waste heat source, such as waste water and waste gas in the factory. Mainly applied in chemical industry, cereals and oils industry, feed processing industry and so on.

Product Description

Type: air to air heat pipe heat exchanger

Function: recover the residual heat of exhaust gas

Operation temperature: 70℃~200℃

Distinguishing feature:

1. high efficiency of heat recovery

2. startup under the small temperature difference and good isothermal condition

3. hard to bring the acid dew point corrosion

4. protecting the fresh air from pollution of waste gas

Material feature: stainless steel base tube with stainless steel fins by high-frequency welding

Array: staggered arrangement

Heat pipe and fin shape

Performance Parameter

Model	Air Flow(m3/h)	Windward Tubes	Effective Length (mm)	Heat Exchange Area (m2)	Total Heat Load (kw)	L×W×H (mm)
Model	Air Flow(m3/h)	Windward Tubes	Effective Length (mm)	Heat Exchange Area (m2)	Total Heat Load (kw)	L×W×H (mm)
RSSS-13×25×0.9	7500	13	992	399	182	1212×2075×860
RSSS-14×25×1	10000	14	1029	533	242	1249×2075×1060
RSSS-14×25×1.1	11000	14	1132	586	267	1352×2075×1060
RSSS-14×25×1.2	12000	14	1235	639	291	1455×2075×1060
RSSS-15×25×1.2	15000	15	1263	799	363	1483×2075×1260
RSSS-16×25×1.3	18000	16	1389	959	436	1609×2075×1360
RSSS-18×25×1.4	20000	18	1425	1065	485	1645×2075×1460
RSSS-18×25×1.5	22000	18	1567	1172	533	1787×2075×1460
RSSS-19×25×1.6	25000	19	1653	1331	606	1873×2075×1560
RSSS-20×25×1.8	30000	20	1852	1598	727	2072×2075×1660

Packaging & Shipping

Packaging according to custmer's requirement

Shipping Port: Shanghai

Application Field

Heat pipe heat exchanger mainly applied in chemical industry, cereals and oils industry, feed processing industry and so on.

ISO Certificate

Company Profile

Wuxi Quanbang Energy Technology Co., Ltd.

Wuxi Quanbang Energy Technology CO.,LTD is a technology enterprise dedicated in heat exchanges industry which has many years professional experience of design and manufacture. Our products are wildly applied in cereals and oil processing, chemical production and boiler etc. We have risen steadily as one of the pioneers and leaders in this industry in china.
